XING Xiuju, JIANG Qiping, WU Zhengfei, LI Wengang, ZHANG Yirui. Three-dimensional transient electromagnetic detection technology of fixed point in full space[J]. COAL GEOLOGY & EXPLORATION, 2018, 46(S1): 60-65. DOI: 10.3969/j.issn.1001-1986.2018.S1.013
Citation: XING Xiuju, JIANG Qiping, WU Zhengfei, LI Wengang, ZHANG Yirui. Three-dimensional transient electromagnetic detection technology of fixed point in full space[J]. COAL GEOLOGY & EXPLORATION, 2018, 46(S1): 60-65. DOI: 10.3969/j.issn.1001-1986.2018.S1.013
shu

Three-dimensional transient electromagnetic detection technology of fixed point in full space

  • Xi'an Research Institute Co. Ltd., China Coal Technology and Engineering Group Corp., Xi'an 710077, China

Funds:

National Natural Science Foundation of China(NSFC41674133)

More Information
  • Received Date: May 10, 2018
  • Published Date: July 24, 2018
    Graphical Abstract
    • Abstract
  • In order to accurately locate and intuitively display the water-conducting structures inside the front of the excavation roadway and in the working face in the results map, based on the original fixed-point three-dimensional transient electromagnetic advance detection technology, the three-dimensional physical simulation technology was used to simulate the water-conducting structures in different spatial locations and shapes in coal mines, and the spatial distribution characteristics of three-dimensional apparent resistivity were analyzed. The results show that the multi-turn small coil has certain directionality. When the normal line of the transceiver coil is close to the simulated body, it will produce a more obvious transient electromagnetic response signal; the water-repellent model with different position and shape, the apparent resistivity of the three-dimensional space of equipotential surface area basically coincides with its actual volumetric dimension. In the application of concealed collapse columns inside the working face 19108 of Jinggongyi Mine No. 1 in Pingshuo, the collapse columns inside the working face can be accurately displayed in the three-dimensional anomaly space, providing effective technical means for geological forecast during drivage excavation and before extraction in a working face.
    • FullText(HTML)
    • References (16)
