| Citation: |
ZHAO Yongzhe，ZHAO Baofeng，HU Zhenyang，et al. Operation strategy simulation of the heating system for moderately deep geothermal resources[J]. Coal Geology & Exploration，2025，53(4)：203−212. DOI: 10.12363/issn.1001-1986.24.12.0820
|
The active utilization of moderately deep geothermal resources for heating serves as a critical measure to achieve the goals of peak carbon dioxide emissions and carbon neutrality. Meanwhile, the effectiveness of the operation strategies of the heating system using these resources directly influences heating performance and significantly affects the energy consumption of the heating system. It is necessary to prevent resource waste while utilizing geothermal energy.
Based on a heating project using moderately deep geothermal resources in the Guanzhong Basin, Shaanxi Province, this study established a dynamic simulation model using the TRNSYS transient simulation software. Then, this study simulated the heating performance and energy consumption of the heating system under five operation strategies and conducted systematic analyses of the temperatures, energy consumption, and operational mechanisms.
The results indicate that during the early and late stages of the heating season, the operation strategy of direct heat exchange via a geothermal well exhibited the highest heating performance. This strategy enabled the room temperature on the user end to reach 32℃, with a peak coefficient of performance (COP) of 19. In contrast, cascading utilization based on a geothermal well and heating pump units was suitable in the case where the water temperature at the outlets of the buried tubes gradually decreased in the middle stage of the heating season. This strategy can maintain the room temperature on the user end at about 30℃ over a short period, with a maximal and minimal COP of 12.75 and 9.06, respectively. In the late stage of the continuous heat supply using a single geothermal well, the heating operation strategy relying primarily on heat pump units can be adopted. This strategy allowed the room temperature on the user end to range from 20 ℃ to 28 ℃ in the short term, with a maximal and minimal COP of 6.99 and 5.22, respectively. In addition, the operation strategy should be dynamically adjusted based on the water temperature at the outlets of buried pipes and the room temperature on the user end under varying application contexts. The overall energy consumption revealed that direct heat transfer via a geothermal well should be preferred and that the start frequency and operational duration of heat pump units should be minimized. For the cascading utilization, one pump unit should be started first, and it is necessary to minimize the number of heat pump units in operation. For the operation strategy of single-well heating, heating relying on heating pump units in the middle to late stage of the heating season led to increased energy consumption. Therefore, an intermittent operation strategy based on multiple wells should be employed where possible. The results of this study can be used to adjust and optimize the operation strategies of the coaxial casing-type buried pipe heat exchanger system for moderately deep geothermal resources while also providing a reference for the design of operation strategies.
| [1] |
曹锐,多吉,李玉彬,等. 我国中深层地热资源赋存特征、发展现状及展望[J]. 工程科学学报,2022,44(10):1623−1631. DOI: 10.3321/j.issn.1001-053X.2022.10.bjkjdxxb202210002
CAO Rui,DUO Ji,LI Yubin,et al. Occurrence characteristics,development status,and prospect of deep high–temperature geothermal resources in China[J]. Chinese Journal of Engineering,2022,44(10):1623−1631. DOI: 10.3321/j.issn.1001-053X.2022.10.bjkjdxxb202210002
|
| [2] |
孙焕泉,毛翔,吴陈冰洁,等. 地热资源勘探开发技术与发展方向[J]. 地学前缘,2024,31(1):400−411.
SUN Huanquan,MAO Xiang,WU Chenbingjie,et al. Geothermal resources exploration and development technology:Current status and development directions[J]. Earth Science Frontiers,2024,31(1):400−411.
|
| [3] |
王贵玲,刘彦广,朱喜,等. 中国地热资源现状及发展趋势[J]. 地学前缘,2020,27(1):1−9.
WANG Guiling,LIU Yanguang,ZHU Xi,et al. The status and development trend of geothermal resources in China[J]. Earth Science Frontiers,2020,27(1):1−9.
|
| [4] |
韩永亮,王凯鹏,王义杰,等. 中深层地热井换热特性多因素影响规律研究[J]. 煤田地质与勘探,2024,52(1):104−116. DOI: 10.12363/issn.1001-1986.23.11.0746
HAN Yongliang,WANG Kaipeng,WANG Yijie,et al. Influencing patterns of multiple factors on the heat transfer performance of moderately deep geothermal wells[J]. Coal Geology & Exploration,2024,52(1):104−116. DOI: 10.12363/issn.1001-1986.23.11.0746
|
| [5] |
杜丁山,赵永哲,胡振阳,等. 隔热内管对中深层地热井同轴换热器换热性能的影响[J]. 煤炭工程,2023,55(2):164−170.
DU Dingshan,ZHAO Yongzhe,HU Zhenyang,et al. Effect of insulated inner tube on performance of coaxial heat exchanger in medium–deep geothermal well[J]. Coal Engineering,2023,55(2):164−170.
|
| [6] |
景登岩,施志钢,刘福强,等. 基于TRNSYS的中深层地热供暖系统运行特性研究[J]. 可再生能源,2022,40(6):751−759. DOI: 10.3969/j.issn.1671-5292.2022.06.007
JING Dengyan,SHI Zhigang,LIU Fuqiang,et al. Study on operation characteristics of the middle–deep geothermal heating system based on TRNSYS[J]. Renewable Energy Resources,2022,40(6):751−759. DOI: 10.3969/j.issn.1671-5292.2022.06.007
|
| [7] |
PAN Aiqiang,LU Lin,CUI Ping,et al. A new analytical heat transfer model for deep borehole heat exchangers with coaxial tubes[J]. International Journal of Heat and Mass Transfer,2019,141:1056−1065.
|
| [8] |
DAI Chuanshan,LI Jiashu,SHI Yu,et al. An experiment on heat extraction from a deep geothermal well using a downhole coaxial open loop design[J]. Applied Energy,2019,252:113447. DOI: 10.1016/j.apenergy.2019.113447
|
| [9] |
鲍玲玲,徐豹,王子勇,等. 中深层同轴套管式地埋管换热器传热性能分析[J]. 地球物理学进展,2020,35(4):1217−1222. DOI: 10.6038/pg2020DD0335
BAO Lingling,XU Bao,WANG Ziyong,et al. Heat transfer performance analysis of the middle–deep coaxial casing ground heat exchanger[J]. Progress in Geophysics,2020,35(4):1217−1222. DOI: 10.6038/pg2020DD0335
|
| [10] |
董红霞. 地热梯级利用供热系统运行策略研究[D]. 天津:天津大学,2011.
DONG Hongxia. Research on the operation strategy of geothermal step utilization for the heat–supply system[D]. Tianjin:Tianjin University,2011.
|
| [11] |
张超,宰相,鲁梦龙,等. 基于TRNSYS的区域供热系统仿真与模型验证[J]. 建筑科学,2021,37(12):103−110.
ZHANG Chao,ZAI Xiang,LU Menglong,et al. Simulation and model validation of regional heating system based on TRNSYS[J]. Building Science,2021,37(12):103−110.
|
| [12] |
李传震. 取水型中深层地热系统联合浅层地源热泵系统在设施农业中的运行策略研究[D]. 杨凌:西北农林科技大学,2023.
LI Chuanzhen. Study on operation strategy of water intake medium and deep geothermal system combined with shallow ground source heat pump system in facility agriculture[D]. Yangling:Northwest A & F University,2023.
|
| [13] |
吴鑫,王乐,王娟芳,等. 中深层地热耦合水源热泵冬季梯级供热系统性能优化[J]. 建筑科学,2024,40(2):56−62.
WU Xin,WANG Le,WANG Juanfang,et al. Study on the optimization of cascade heating system of middle–deep geothermal coupled water source heat pump in winter[J]. Building Science,2024,40(2):56−62.
|
| [14] |
LU Shilei,LI Caihong,WANG Ran,et al. Research on the day–ahead scheduling optimization method of medium–depth geothermal cascade heating system[J]. Journal of Building Engineering,2024,82:108184. DOI: 10.1016/j.jobe.2023.108184
|
| [15] |
LI Jianwei,BAO Lingling,NIU Guoqing,et al. Research on renewable energy coupling system based on medium–deep ground temperature attenuation[J]. Applied Energy,2024,353:122187. DOI: 10.1016/j.apenergy.2023.122187
|
| [16] |
LI Yiming,QIAN Suxin. Field test of a ground–source heat pump system and numerical investigation on advanced control strategies[J]. Applied Thermal Engineering,2024,246:123008. DOI: 10.1016/j.applthermaleng.2024.123008
|
| [17] |
王凯鹏,韩永亮,汪启龙,等. 基于Trnsys的地源热泵+冷却塔复合系统运行特性模拟研究[J]. 节能,2023,42(3):26−29. DOI: 10.3969/j.issn.1004-7948.2023.03.007
WANG Kaipeng,HAN Yongliang,WANG Qilong,et al. Simulation research on operation characteristics of ground source heat pump and cooling tower composite system based on TRNSYS[J]. Energy Conservation,2023,42(3):26−29. DOI: 10.3969/j.issn.1004-7948.2023.03.007
|
| [18] |
李松波. 混合式地源热泵系统的TRNSYS模拟研究[D]. 广州:广东工业大学,2013.
LI Songbo. Simulation with TRNSYS for hybrid ground–source heat pump systems[D]. Guangzhou:Guangdong University of Technology,2013.
|
| [19] |
方亮. 地源热泵系统中深层地埋管换热器的传热分析及其应用[D]. 济南:山东建筑大学,2018.
FANG Liang. Heat transfer analysis and application of deep borehole heat exchanger in ground source heat pump systems[D]. Jinan:Shandong Jianzhu University,2018.
|
| [20] |
吕沛志. 无干扰地岩热能梯级利用系统的优化[D]. 西安:西安石油大学,2019.
LYU Peizhi. Optimization of non-interfering geothermal energy cascade utilization system[D]. Xi’an:Xi’an Shiyou University,2019.
|
| [21] |
景登岩. 中深层地热套管式地埋管热泵换热系统研究[D]. 青岛:青岛理工大学,2021.
JING Dengyan. Study on heat exchange system of geothermal bushing buried pipe heat pump in middle and deep layer[D]. Qingdao:Qingdao University of Technology,2021.
|
| [22] |
荆强. 基于TRNSYS的校园供热系统优化运行控制研究[D]. 哈尔滨:哈尔滨工业大学,2020.
JING Qiang. Research on optimal operation control of campus heating system based on TRNSYS[D]. Harbin:Harbin Institute of Technology,2020.
|
| [23] |
牛凡. 校园供热系统优化运行控制策略研究[D]. 哈尔滨:哈尔滨工业大学,2019.
NIU Fan. Research on optimal operation control strategy of campus heating system[D]. Harbin:Harbin Institute of Technology,2019.
|
| [24] |
朱超,师鹏,张拓,等. 蓄热式中深层地热供暖系统运行策略分析[J]. 真空与低温,2024,30(2):196−205.
ZHU Chao,SHI Peng,ZHANG Tuo,et al. Analysis of the operation strategy for heat storage middle–deep geothermal heating system[J]. Vacuum and Cryogenics,2024,30(2):196−205.
|
| [25] |
屈晓红. 地热工程监控系统设计及运行数据分析方法研究[D]. 北京:中国矿业大学(北京),2010.
QU Xiaohong. Research on design and run date analysis of auto control system for the 3th generation in geothermal engineering[D]. Beijing:China University of Mining and Technology (Beijing),2010.
|
| [26] |
张哲菲,刘洪涛,刘攀峰,等. 中深层地热地埋管实际运行影响因素研究[J]. 太阳能学报,2022,43(12):503−509.
ZHANG Zhefei,LIU Hongtao,LIU Panfeng,et al. Study on actual operation and influencing factors of middle–deep geothermal buried pipe[J]. Acta Energiae Solaris Sinica,2022,43(12):503−509.
|
| [27] |
王泽轩. 严寒地区高速服务区建筑多能互补清洁供暖系统研究[D]. 哈尔滨:哈尔滨商业大学,2023.
WANG Zexuan. Study on multi–source complementary heating system in buildings of high–speed service area in severe cold region[D]. Harbin:Harbin University of Commerce,2023.
|
| [28] |
LI Zhiwei,LIU Junjie,JIA Lizhi,et al. Improving room temperature stability and operation efficiency using a model predictive control method for a district heating station[J]. Energy and Buildings,2023,287:112990.
|
| [29] |
LI Zhiwei,LIU Junjie,ZHANG Jian,et al. A hybrid control method for district heating substations based on time–based room temperature demand[J]. Energy and Buildings,2023,297:113467.
|
| [30] |
李艳斌,张勇,刘轩,等. 工业园区中深层地热能梯级利用供暖系统应用及效益分析[J]. 西北水电,2023(3):37−41. DOI: 10.3969/j.issn.1006-2610.2023.03.008
LI Yanbin,ZHANG Yong,LIU Xuan,et al. Application and benefit analysis of medium and deep geothermal energy cascade utilization heating system in industrial parks[J]. Northwest Hydropower,2023(3):37−41. DOI: 10.3969/j.issn.1006-2610.2023.03.008
|
| [31] |
中华人民共和国住房和城乡建设部,中华人民共和国国家质量监督检验检疫总局. 煤炭工业供暖通风与空气调节设计标准:GB/T 50466—2018[S]. 北京:中国计划出版社,2018.
|
