An acoustic velocity inversion method based on convolutional autoencoder-Fourier neural operator
-
摘要: 【背景】 地震波反演是利用地震波的到达时间、振幅和波形等信息获取地下介质构造、岩性和物性特征的有效手段。基于波动方程的地震反演方法利用正演模拟技术不断迭代更新模型参数，这通常需要大量的数值模拟和优化计算，耗费大量的计算资源和时间。近年来，以傅里叶神经算子(FNO)为代表的神经算子学习引起了广泛关注。然而，在复杂介质地震波反演中，原始FNO结构无法有效学习地质结构变化剧烈的波场信息，导致其反演结果准确性不高。【目的和方法】 为了提升FNO在复杂地质模型下学习地震波场信息的准确性和泛化性能，提出了一种新颖的声波速度反演方法——卷积自编码傅里叶神经算子(CAE-FNO)。CAE-FNO利用编码器进行特征提取，并基于FNO进行高效训练，以更好地捕捉波场的细微特征并提高预测精度。CAE-FNO在网络训练过程中逐层减小傅立叶模的规模，从而有效减少网络参数的数量，同时增强网络的泛化能力。【结果和结论】 通过对均匀、非均匀、层状和Marmousi2等模型进行数值实验验证，结果表明： CAE-FNO的反演精度显著优于FNO及其变体UFNO和UNO。在均匀介质模型中，CAE-FNO的速度反演结果相对误差为1.3%，而UFNO与UNO的反演结果相对误差分别为1.7%、2.3%，FNO的误差高达10.1%。在非均匀模型中，CAE-FNO准确反演地质结构和速度变化位置，而UFNO和UNO在速度变化剧烈区域的误差相对较大。层状模型中，CAE-FNO能够清晰区分不同层间的微小速度变化，而FNO无法明显区分。在Marmousi2模型的平滑区域和突变区域，CAE-FNO较UFNO和UNO更能准确捕捉不规则的速度变化界面，FNO则无法有效处理这些区域的速度突变与细节变化。CAE-FNO通过更低的损失函数值和更高的反演精度，展示了其在复杂介质反演中的优势，为地震反演技术提供新的研究思路。Abstract: [Background] Seismic wave inversion serves as an effective method for obtaining the characteristics of structures, lithology, and physical properties of subsurface media using the arrival times, amplitude, and waveforms of seismic waves. Seismic inversion methods based on wave equations iteratively update model parameters using forward modeling. This generally involves extensive numerical simulations and optimization calculations, requiring large quantities of computational resources and time. In recent years, neural operators for deep learning, represented by the Fourier neural operator (FNO), have gained widespread attention. However, the original FNO structure fails to effectively learn the wavefield information with sharp changes in geological structures in the seismic wave inversion of complex media, leading to low accuracy of inversion results. [Objective and Methods] To enhance the accuracy and generalization performance of FNO in learning seismic wavefield information under complex geological models, this study developed a novel acoustic velocity inversion method—Fourier neural operator based on convolutional autoencoder (CAE-FNO), which utilized an encoder for feature extraction and performed efficient training based on FNO to effectively capture the fine features of the seismic wavefield and improved prediction accuracy. During the network training, the CAE-FNO method progressively reduced the size of the Fourier mode, thus effectively reducing the number of network parameters while enhancing the generalization capability of the network. [Results and Conclusions] The numerical experiments on homogeneous, heterogeneous, layered, and Marmousi2 models demonstrate that the CAE-FNO method exhibited significantly higher inversion accuracy than FNO and its variants UFNO and UNO. The experiments on the homogeneous model revealed that the velocity inversion results of the CAE-FNO method had a relative error of 1.3% and those of UFNO, UNO, and FNO exhibited relative errors of 1.7%, 2.3%, and up to 10.1%, respectively. In the experiments on the heterogeneous model, CAE-FNO yielded accurate inversion results of geological structures and velocity change positions, whereas UFNO and UNO exhibited higher errors for zones with sharp velocity fluctuations. During the experiments on the layered model, CAE-FNO clearly distinguished minor velocity changes between layers, while FNO failed. For both smooth zones and zones with abrupt changes in the Marmousi2 model, CAE-FNO exhibited higher accuracy in capturing irregular interfaces with velocity changes than UFNO and UNO, while FNO failed to effectively handle the abrupt changes in velocity and detail changes in these zones. Therefore, the CAE-FNO method, demonstrating small loss functions and high accuracy, enjoys advantages in the inversion of complex media, providing a novel research philosophy for seismic inversion.
-
-
[1] 杨培杰. 砂泥岩储层孔隙度和含水饱和度同步反演[J]. 地球物理学报，2018，61(2)：673–682. YANG Peijie. Porosity and water saturation simultaneous inversion for sand-mudstone reservoir[J]. Chinese Journal of Geophysics，2018，61(2)：673–682. [2] 韩宏伟，程远锋，张云银，等. 储层物性的地震预测技术综述[J]. 地球物理学进展，2021，36(2)：595–610. HAN Hongwei，CHENG Yuanfeng，ZHANG Yunyin，et al. Review of seismic prediction of reservoir geophysical properties[J]. Progress in Geophysics，2021，36(2)：595–610.
[3] CHOPRA S，MARFURT K J. Seismic attributes—a historical perspective[J]. Geophysics，2005，70(5)：3SO–28SO.
[4] VIRIEUX J，OPERTO S. An overview of full-waveform inversion in exploration geophysics[J]. Geophysics，2009，74(6)：WCC127.
[5] ZELT C A，SMITH R B. Seismic traveltime inversion for 2-D crustal velocity structure[J]. Geophysical Journal International，1992，108(1)：16–34.
[6] RASHT-BEHESHT M，HUBER C，SHUKLA K，et al. Physics-informed neural networks (PINNs) for wave propagation and full waveform inversions[J]. Journal of Geophysical Research：Solid Earth，2022，127(5)：e2021JB023120.
[7] DWIVEDI V，PARASHAR N，SRINIVASAN B. Distributed physics informed neural network for data-efficient solution to partial differential equations[EB/OL]. 2019：1907.08967. https：//arxiv. org/abs/1907.08967v1
[8] MENG Xuhui，LI Zhen，ZHANG Dongkun，et al. PPINN：Parareal physics-informed neural network for time-dependent PDEs[J]. Computer Methods in Applied Mechanics and Engineering，2020，370：113250.
[9] WU Chenxi，ZHU Min，TAN Qinyang，et al. A comprehensive study of non-adaptive and residual-based adaptive sampling for physics-informed neural networks[J]. Computer Methods in Applied Mechanics and Engineering，2023，403：115671.
[10] CHEN Yanlai，KOOHY S. GPT-PINN：Generative Pre-Trained Physics-Informed Neural Networks toward non-intrusive Meta-learning of parametric PDEs[J]. Finite Elements in Analysis and Design，2024，228：104047.
[11] SONG Chao，LIU Yang，ZHAO Pengfei，et al. Simulating multicomponent elastic seismic wavefield using deep learning[J]. IEEE Geoscience and Remote Sensing Letters，2023，20：3001105.
[12] WU Yanqi，AGHAMIRY H S，OPERTO S，et al. Helmholtz-equation solution in nonsmooth media by a physics-informed neural network incorporating quadratic terms and a perfectly matching layer condition[J]. Geophysics，2023，88(4)：T185–T202.
[13] SONG Chao，ALKHALIFAH T，WAHEED U B. Solving the frequency-domain acoustic VTI wave equation using physics-informed neural networks[J]. Geophysical Journal International，2021，225(2)：846–859.
[14] SONG Chao，ALKHALIFAH T A. Wavefield reconstruction inversion via physics-informed neural networks[J]. IEEE Transactions on Geoscience and Remote Sensing，2022，60：5908012.
[15] SHAKEEL M，NISHIDA K，ITOYAMA K，et al. 3D convolution recurrent neural networks for multi-label earthquake magnitude classification[J]. Applied Sciences，2022，12(4)：2195.
[16] BERHICH A，BELOUADHA F Z，KABBAJ M I. LSTM-based models for earthquake prediction[C]//Proceedings of the 3rd International Conference on Networking，Information Systems & Security. Marrakech Morocco. ACM，2020.
[17] ZHENG Qiqi，WEI Chao，YAN Xinfei，et al. Seismic elastic parameter inversion via a FCRN and GRU hybrid network with multi-task learning[J]. Applied Sciences，2023，13(18)：10519.
[18] MOUSAVI S M，ELLSWORTH W L，ZHU Weiqiang，et al. Earthquake transformer-an attentive deep-learning model for simultaneous earthquake detection and phase picking[J]. Nature Communications，2020，11(1)：3952.
[19] WANG Tiantong，TRUGMAN D，LIN Youzuo. SeismoGen：Seismic waveform synthesis using GAN with application to seismic data augmentation[J]. Journal of Geophysical Research：Solid Earth，2021，126(4)：e2020JB020077.
[20] LI Zongyi，KOVACHKI N，AZIZZADENESHELI K，et al. Neural operator：Graph kernel network for partial differential equations[J]. ArXiv e-Prints，2020：arXiv：2003.03485.
[21] LU Lu，JIN Pengzhan，PANG Guofei，et al. Learning nonlinear operators via DeepONet based on the universal approximation theorem of operators[J]. Nature Machine Intelligence，2021，3(3)：218–229.
[22] CAI Shengze，WANG Zhicheng，LU Lu，et al. DeepM\&Mnet：Inferring the electroconvection multiphysics fields based on operator approximation by neural networks[J]. Journal of Computational Physics，2021，436：110296.
[23] CAO Qianying，GOSWAMI S，KARNIADAKIS G. LNO：Laplace neural operator for solving differential equations[J]. Nat. Mac. Intell. ，2023，6：631–640.
[24] LI Z, KOVACHKI N, AZIZZADENESHELI K, et al. Fourier neural operator for parametric partial differential equations [J]. arXiv preprint arXiv:201008895, 2020.
[25] LI Bian，WANG Hanchen，FENG Shihang，et al. Solving seismic wave equations on variable velocity models with Fourier neural operator[J]. IEEE Transactions on Geoscience and Remote Sensing，2023，61：4508618.
[26] SONG Chao，WANG Yanghua. High-frequency wavefield extrapolation using the Fourier neural operator[J]. Journal of Geophysics and Engineering，2022，19(2)：269–282.
[27] 潘代英，何清龙. 基于改进的傅里叶神经算子数值求解频率域声波方程[J]. 运筹与模糊学，2023，13(6)：5978–5990. PAN Daiying，HE Qinglong. Numerical solution of frequency-domain acoustic wave equation based on improved Fourier neural operator[J]. Operations Research and Fuzziology，2023，13(6)：5978–5990. [28] YANG Yan，GAO A F，AZIZZADENESHELI K，et al. Rapid seismic waveform modeling and inversion with neural operators[J]. IEEE Transactions on Geoscience and Remote Sensing，2023，61：5906712.
[29] WEN Gege，LI Zongyi，AZIZZADENESHELI K，et al. U-FNO—An enhanced Fourier neural operator-based deep-learning model for multiphase flow[J]. Advances in Water Resources，2022，163：104180.
[30] RAHMAN M A，ROSS Z E，AZIZZADENESHELI K. U-NO：U-shaped neural operators[J]. ArXiv e-Prints，2022：arXiv：2204.11127.
[31] KONUK T，SHRAGGE J. Physics-guided deep learning using Fourier neural operators for solving the acoustic VTI wave equation[C]//82nd EAGE Annual Conference & Exhibition. Amsterdam，The Netherlands，. European Association of Geoscientists & Engineers，2021.
[32] LEHMANN F，GATTI F，BERTIN M，et al. Fourier neural operator surrogate model to predict 3D seismic waves propagation[J]. ArXiv e-Prints，2023：arXiv：2304.10242.
[33] LEHMANN F，GATTI F，BERTIN M，et al. 3D elastic wave propagation with a Factorized Fourier Neural Operator (F-FNO)[J]. Computer Methods in Applied Mechanics and Engineering，2024，420：116718.
[34] LEHMANN F, GATTI F, BERTIN M, et al. Seismic hazard analysis with a Factorized Fourier Neural Operator (F-FNO) surrogate model enhanced by transfer learning; proceedings of the NeurIPS 2023 AI for Science Workshop, F, 2023[C].
[35] ZHANG Yijie，ZHU Xueyu，GAO Jinghuai. Parameter estimation of acoustic wave equations using hidden physics models[J]. IEEE Transactions on Geoscience and Remote Sensing，2020，58(7)：4629–4639.
[36] TARANTOLA A. Inversion of seismic reflection data in the acoustic approximation[J]. Geophysics，1984，49(8)：1259.
