Risk assessment of water inrush from coal seam floors based on multiple methods
-
摘要: 选择平顶山煤田二矿、十矿和十二矿51个钻孔的隔水层厚度、断层复杂程度、含水层水压、含水层单位涌水量、采高5个因素为评价因子，以层次分析法和灰色关联分析法计算的常权权重为基础，应用变权理论确定各指标因子的变权权重；分别利用物元可拓法、模糊可变集理论、突变理论、模糊综合评价法，对煤层底板突水危险性进行评价并确定突水危险性等级。与实际开采情况的对比分析证明，模糊可变集理论是最适宜研究区的底板突水危险性评价方法，评价结果与开采实际较为吻合。模糊可变集理论的评价表明，二矿、十矿、十二矿带压区内安全区占比分别为4.08%、14.30%、0，低威胁区占比分别为76.91%、83.14%、85.78%，高威胁区占比分别为19.01%、2.56%、14.22%，研究区内暂无危险区。Abstract: Five factors including the thickness of the aquifer, the complexity of the fault, the water pressure of the aquifer, the unit water inflow of the aquifer, and mining height of 51 boreholes in No.2, No.10 and No.12 Coal Mines of Pingdingshan Coalfield are selected as the index factors. On the basis of the constant weight calculated by the analytic hierarchy process and grey relational analysis, the variable weights of each index factor are determined by applying the variable weight theory. By using the matter-element extension method, fuzzy variable set theory, catastrophe theory, and fuzzy comprehensive evaluation method, the water inrush risk of coal seam floors is evaluated and the water inrush risk grade is determined. The comparative analysis of the actual mining situation shows that the fuzzy variable set theory is the most suitable method for risk evaluation of floor water inrush in the study area, and its evaluation results are more consistent with the actual situation. The evaluation based on the fuzzy variable set theory shows that the proportions of safety zones in the pressure zones of No.2, No.10 and No.12 Coal Mine are 4.08%, 14.30% and 0 respectively; the proportions of low threat zones are 76.91%, 83.14% and 85.78% respectively; and the proportions of high threat zones are 19.01%, 2.56% and 14.22% respectively. There is no danger zones in the study area temporarily.
-
-
![]()
图 1 平煤3矿带压开采区分布
Fig. 1 Distribution of the mining area under pressure in three coal mines of Pingdingshan Coalfield
表 1 指标因子赋值结果
Table 1 Quantitative results of index factors
钻孔
编号水压/
MPa单位涌水量/
(L·s–1·m–1)采高/m 隔水层厚度/
m断层分维值 钻孔
编号水压/
MPa单位涌水量/
(L·s–1·m–1)采高/m 隔水层厚度/
m断层分维值 2-1 0.5264 0.1823 1.7857 15.7078 0.8873 10-14 0.5043 0.0260 3.2647 81.542 0 0.7971 2-2 0.5498 0.5179 1.1823 13.6815 0.8451 10-15 0.5423 0.0282 3.1189 82.1374 0.9044 2-3 0.5951 1.0808 0.8679 17.7004 0.8109 10-16 0.5993 0.0302 3.0602 82.4651 0.9421 2-4 0.5422 0.9490 1.3912 26.4058 0.8187 10-17 2.7756 0.0598 3.6500 80.4300 0.7061 2-5 0.4305 0.1383 1.8936 17.3044 0.8994 10-18 2.8397 0.0422 5.9700 90.8400 0.7189 2-6 0.4690 0.5098 1.0765 14.4888 0.8094 10-19 2.3782 0.0423 6.0500 80.7900 0.7263 2-7 0.4893 0.8019 0.5544 15.2181 0.7758 10-20 2.0213 0.0500 6.8500 80.4600 0.6412 2-8 0.4766 0.8624 1.2257 26.6466 0.7710 均值 1.2589 0.0373 3.4389 81.6309 0.7712 2-9 0.6630 0.8510 2.0224 21.4843 1.0173 12-1 2.4407 0.2270 3.8264 96.5309 1.3096 2-10 0.5544 0.6932 0.4939 47.7589 1.0935 12-2 2.2979 0.2171 3.8397 96.1909 1.4242 2-11 0.5196 0.5300 1.3141 24.6479 1.0710 12-3 2.1736 0.2102 3.8456 95.9022 1.4172 2-12 0.5008 0.4043 1.2788 27.4785 1.2944 12-4 2.0924 0.2070 3.8452 95.7255 1.3979 2-13 0.4200 0.2901 0.4778 44.9826 0.9643 12-5 1.9033 0.1772 3.886 0 95.4657 1.3484 均值 0.5182 0.6008 1.1973 24.1158 0.9275 12-6 1.9769 0.1762 3.8932 95.6592 1.3415 10-1 1.4983 0.0445 3.7437 80.4339 0.6467 12-7 2.0958 0.1744 3.8988 96.0221 1.2593 10-2 1.4933 0.0424 2.8745 80.7430 0.8418 12-8 2.2692 0.1695 3.8883 96.6785 1.0193 10-3 1.4670 0.0405 2.1031 81.3042 0.8663 12-9 2.3353 0.1607 4.2111 85.0839 0.9195 10-4 1.3477 0.0398 1.8075 81.3466 0.8758 12-10 2.2600 0.1721 4.3811 85.2341 1.0433 10-5 1.2036 0.0387 1.4863 81.3504 0.8690 12-11 2.2195 0.1715 4.4278 85.2874 1.0911 10-6 1.1725 0.0396 1.8767 80.8842 0.9033 12-12 1.9786 0.1560 4.3077 85.5304 1.2130 10-7 1.1372 0.0414 2.6234 80.4273 0.7367 12-13 1.7789 0.1271 3.9184 85.8249 1.1442 10-8 1.1241 0.0436 3.2502 80.2976 0.4695 12-14 1.8601 0.1044 3.7705 85.6541 0.9105 10-9 0.6766 0.0309 3.1735 82.2445 0.9084 12-15 1.8642 0.0198 3.3054 85.2398 0.7989 10-10 0.6599 0.0294 3.2959 81.9122 0.8618 12-16 2.9500 0.3318 5.7449 84.9238 0.9477 10-11 0.6327 0.0262 3.5113 81.2258 0.7215 12-17 2.7900 0.3176 4.6595 84.6951 0.8017 10-12 0.6269 0.0248 3.6117 80.8190 0.6152 12-18 2.2300 0.0297 3.7427 84.3192 0.7926 10-13 0.4779 0.0247 3.4556 80.9642 0.6712 均值 2.1954 0.1750 4.0774 89.9982 1.1211
下载: 导出CSV
表 2 各指标对应的变权区间
Table 2 Variable weight intervals of each index
评价因子 惩罚区间 不激励不惩罚区间 初激励区间 强激励区间 水压 0≤x<0.1899 0.1899≤x<0.4817 0.4817≤x<0.8649 0.8649≤x≤1 单位涌水量 0≤x<0.2250 0.2250≤x<0.5578 0.5578≤x<0.8350 0.8350≤x≤1 采高 0≤x<0.1508 0.1508≤x<0.3564 0.3564≤x<0.7414 0.7414≤x≤1 隔水层厚度 0≤x<0.0157 0.0157≤x<0.1012 0.1012≤x<0.3023 0.3023≤x≤1 断层分维值 0≤x<0.2978 0.2978≤x<0.4832 0.4832≤x<0.7427 0.7427≤x≤1
下载: 导出CSV
表 3 不同参数条件下的计算结果
Table 3 Calculation results under different parameter conditions
参数 k=1, p=1 k=2, p=1 k=1, p=2 k=2, p=2 $\bar H$ 级别特征值 2.031 3 1.972 3 2.112 7 2.049 8 2.046 4
下载: 导出CSV
表 4 突水危险性评价指标及结果
Table 4 Water inrush risk assessment indexes and results
评价方法 不同指标评价结果 水压 单位涌
水量采高 隔水层
厚度断层复
杂程度初始隶属函数 0.342 8 0.104 7 0.765 0 0.209 2 1 初始突变级数 0.585 5 0.471 3 0.874 6 0.593 6 1 中间变量指标值 0.528 4 0.734 1 1 中间突变级数值 0.726 9 0.902 1 1 总突变隶属函数值 0.876 3
下载: 导出CSV
表 5 不同方法的底板突水危险性评价结果
Table 5 Risk assessment results by different methods
钻孔编号 物元
可拓法模糊
可变集突变
理论模糊
综合评判钻孔编号 物元
可拓法模糊
可变集突变
理论模糊
综合评判2-1 Ⅱ Ⅱ Ⅰ Ⅰ 10-14 Ⅱ Ⅱ Ⅰ Ⅰ 2-2 Ⅲ Ⅲ Ⅱ Ⅰ 10-15 Ⅱ Ⅱ Ⅲ Ⅱ 2-3 Ⅲ Ⅲ Ⅲ Ⅲ 10-16 Ⅱ Ⅱ Ⅲ Ⅱ 2-4 Ⅱ Ⅱ Ⅱ Ⅰ 10-17 Ⅰ Ⅱ Ⅲ Ⅲ 2-5 Ⅱ Ⅱ Ⅰ Ⅱ 10-18 Ⅰ Ⅱ Ⅱ Ⅰ 2-6 Ⅱ Ⅱ Ⅱ Ⅰ 10-19 Ⅰ Ⅱ Ⅱ Ⅳ 2-7 Ⅲ Ⅲ Ⅲ Ⅰ 10-20 Ⅰ Ⅱ Ⅲ Ⅲ 2-8 Ⅱ Ⅱ Ⅰ Ⅰ 12-1 Ⅲ Ⅲ Ⅱ Ⅲ 2-9 Ⅱ Ⅱ Ⅱ Ⅰ 12-2 Ⅲ Ⅲ Ⅱ Ⅲ 2-10 Ⅰ Ⅱ Ⅲ Ⅰ 12-3 Ⅱ Ⅲ Ⅱ Ⅱ 2-11 Ⅱ Ⅱ Ⅱ Ⅰ 12-4 Ⅱ Ⅱ Ⅰ Ⅲ 2-12 Ⅱ Ⅱ Ⅲ Ⅱ 12-5 Ⅱ Ⅱ Ⅰ Ⅲ 2-13 Ⅰ Ⅰ Ⅱ Ⅰ 12-6 Ⅱ Ⅱ Ⅰ Ⅲ 10-1 Ⅰ Ⅱ Ⅱ Ⅰ 12-7 Ⅱ Ⅱ Ⅰ Ⅲ 10-2 Ⅲ Ⅲ Ⅱ Ⅳ 12-8 Ⅱ Ⅱ Ⅰ Ⅳ 10-3 Ⅲ Ⅲ Ⅱ Ⅳ 12-9 Ⅱ Ⅱ Ⅰ Ⅲ 10-4 Ⅲ Ⅲ Ⅱ Ⅳ 12-10 Ⅱ Ⅱ Ⅰ Ⅲ 10-5 Ⅲ Ⅱ Ⅱ Ⅱ 12-11 Ⅱ Ⅲ Ⅰ Ⅲ 10-6 Ⅱ Ⅲ Ⅲ Ⅱ 12-12 Ⅱ Ⅱ Ⅰ Ⅲ 10-7 Ⅱ Ⅱ Ⅱ Ⅱ 12-13 Ⅱ Ⅱ Ⅰ Ⅲ 10-8 Ⅰ Ⅱ Ⅱ Ⅱ 12-14 Ⅰ Ⅱ Ⅰ Ⅲ 10-9 Ⅱ Ⅱ Ⅲ Ⅱ 12-15 Ⅰ Ⅱ Ⅰ Ⅰ 10-10 Ⅱ Ⅱ Ⅱ Ⅱ 12-16 Ⅰ Ⅲ Ⅲ Ⅲ 10-11 Ⅰ Ⅱ Ⅰ Ⅲ 12-17 Ⅰ Ⅱ Ⅱ Ⅲ 10-12 Ⅰ Ⅱ Ⅰ Ⅱ 12-18 Ⅰ Ⅱ Ⅱ Ⅲ 10-13 Ⅰ Ⅱ Ⅰ Ⅰ
下载: 导出CSV
表 6 二矿有效隔水层厚度
Table 6 Effective aquiclude thickness of No.2 Coal Mine
钻孔编号 隔水层厚度/m 有效隔水层厚度/m 钻孔编号 隔水层厚度/m 有效隔水层厚度/m 2-1 15.707 8 −4.412 2 2-8 26.646 6 6.526 6 2-2 13.681 5 −6.438 5 2-9 21.484 3 1.364 3 2-3 17.700 4 −2.419 6 2-10 47.758 9 27.638 9 2-4 26.405 8 6.285 8 2-11 24.647 9 4.527 9 2-5 17.304 4 −2.815 6 2-12 27.478 5 7.358 5 2-6 14.488 8 −5.631 2 2-13 44.982 6 24.862 6 2-7 15.218 1 −4.901 9 均值 24.12 3.99
下载: 导出CSV
表 7 分区面积及其所占带压区比例
Table 7 Zoning areas and the proportions in the pressure zones
矿井名称 带压区域面积/km2 安全区 低威胁区 高威胁区 面积/km2 占比/% 面积/km2 占比/% 面积/km2 占比/% 二矿 14.20 0.58 4.08 10.92 76.91 2.70 19.01 十矿 53.35 7.63 14.30 44.23 83.14 1.49 2.56 十二矿 27.81 0 0 23.86 85.78 3.95 14.22
下载: 导出CSV
-
