基于CBM-SIM的梨树煤矿瓦斯地面抽采数值模拟

李晓龙, 张红强, 姜在炳

李晓龙, 张红强, 姜在炳. 基于CBM-SIM的梨树煤矿瓦斯地面抽采数值模拟[J]. 煤田地质与勘探, 2018, 46(1): 41-45. DOI: 10.3969/j.issn.1001-1986.2018.01.007
引用本文: 李晓龙, 张红强, 姜在炳. 基于CBM-SIM的梨树煤矿瓦斯地面抽采数值模拟[J]. 煤田地质与勘探, 2018, 46(1): 41-45. DOI: 10.3969/j.issn.1001-1986.2018.01.007
shu
LI Xiaolong, ZHANG Hongqiang, JIANG Zaibing. Numerical simulation of surface gas extraction based on CBM-SIM in Lishu coal mine[J]. COAL GEOLOGY & EXPLORATION, 2018, 46(1): 41-45. DOI: 10.3969/j.issn.1001-1986.2018.01.007
Citation: LI Xiaolong, ZHANG Hongqiang, JIANG Zaibing. Numerical simulation of surface gas extraction based on CBM-SIM in Lishu coal mine[J]. COAL GEOLOGY & EXPLORATION, 2018, 46(1): 41-45. DOI: 10.3969/j.issn.1001-1986.2018.01.007
shu



基于CBM-SIM的梨树煤矿瓦斯地面抽采数值模拟

  • 1. 中煤科工集团西安研究院有限公司，陕西 西安 710077;

  • 2. 陕西省地质调查院，陕西 西安 710054

基金项目:

国家科技重大专项课题（2016ZX05040-003）

详细信息
    作者简介:

    李晓龙,1989年生,男,陕西澄城人,助理工程师,从事矿井地质与地质灾害防治的研究工作.E-mail:lixiaolong@cctegxian.com

  • 中图分类号: PD713

Numerical simulation of surface gas extraction based on CBM-SIM in Lishu coal mine

  • 1. Xi'an Research Institute, China Coal Technology and Engineering Group Corp., Xi'an 710077, China;

  • 2. Shaanxi Institute of Geological Survey, Xi'an 710054, China

Funds:

National Science and Technology Major Project(2016ZX05040-003)

摘要

    摘要
  • 摘要: 针对煤矿准备区、规划区瓦斯抽采的时空接续要求不同，基于黑龙江鸡西梨树煤矿瓦斯地面抽采试验井，利用CBM-SIM数值模拟软件对已有试验井的生产数据进行历史拟合，实现了储层的精确表征。通过CBM-SIM软件模拟井组抽采5 a、10 a、15 a的产气情况，以及抽采5 a瓦斯含量动态变化情况，最终确定了不同区域的最佳井间距。模拟结果表明，准备区和规划区最优井间距分别为200 m×250 m和300 m×300 m。准备区布井7口，规划区布井64口；准备区抽采5 a采收率为32.30%~38.20%，瓦斯含量可降至8 m3/t以下，满足矿井安全生产。规划区抽采5 a，采收率为30.00%~39.05%；抽采10 a，采收率为41.78%~52.06%，除规划区Ⅲ、Ⅴ以外，其他区域瓦斯含量均可降低至8 m3/t以下；抽采15 a，采收率为48.20%~62.04%，除规划区Ⅴ以外，其他区域瓦斯含量均可降低至8 m3/t以下。研究成果可为梨树煤矿及其东北其他矿区深部薄煤层区的煤与瓦斯协同共采提供借鉴。
    Abstract: To meet different requirements of time and space for gas extraction in preparation and planning area, based on the coalbed methane well test in Lishu coal mine, coalbed methane simulation software CBM-SIM was used to do history match and achieve precise reservoir parameters. For vertical wells in rectangular pattern, CBM-SIM was applied to predict gas rate for 5 years, 10 years and 15 years for 7 diffrent kinds of well spacing, and the dynamic change of gas content for 5 years, eventually determine the best well spacing in different area. Based on the above conclusion, considering all factors, wells were drilled in Lishu coal mine, and gas extraction was predicted by simulation. The results of the study show that the optimal well spacing for preparation areas is 200m×250m and 300 m×300 m for planning areas. 7 wells were placed in preparation areas and 64 wells in planning areas; the recovery ratio for 5 years in the preparation area will be 32.30%~38.20%, the gas content can be reduced to below 8 m3/t, meeting the requirements for safe production in the mine; the recovery ratio in the planning area will be 30.00%~39.05% for 5 years, 41.78%~52.06% for 10 years. Except the planning areas and Ⅲ Ⅴ, the gas content can be decreased to below 8 m3/t in other areas, for extraction for 15 years, the recovery ratio will be 48.20%~62.04%. The research results provide reference for the coal and gas co-extraction in Lishu coal mine and other mining areas of the deep thin coal seam in Northeast China.
    • HTML全文
    • 参考文献(14)
  • [1] 郭继圣,张宝优. 我国煤层气(煤矿瓦斯)开发利用现状及展望[J]. 煤炭工程,2017,49(3):83-86.

    GUO Jisheng,ZHANG Baoyou. Present situation and prospect of coalbed methane development and utilization in China[J]. Coal Engineering,2017,49(3):83-86.
    [2] 谢和平,周宏伟,薛东杰,等. 我国煤与瓦斯共采:理论、技术与工程[J]. 煤炭学报,2014,39(8):1391-1397.

    XIE Heping,ZHOU Hongwei,XUE Dongjie,et al. Theory, technology and engineering of simultaneous exploition of coal and gas in China[J]. Journal of China Coal Society,2014,39(8):1391-1397.
    [3] 周德昶. 地面钻井抽采瓦斯技术的发展方向[J]. 中国煤层气, 2007,4(1):77-79.

    ZHOU Dechang. Development trend of CBM surface well drilling technology[J]. China Coalbed Methane,2007,4(1):77-79.
    [4] 李林. 鸡西盆地梨树煤矿地面煤层气开发井网部署优化研究[J]. 中国煤炭地质,2015,27(11):5-8.

    LI Lin. CBM Exploitation well pattern layout optimization study in lishu coalmine,jixi basin[J]. Coal Geology of China,2015, 27(11):5-8.
    [5] 杜维甲. 影响鸡西盆地煤层气赋存的地质因素[J]. 辽宁工程技术大学学报,2009,28(2):189-191.

    DU Weijia. Impact of Jixi basin coalbed methane occurrence of geological factors[J]. Journal of Liaoning Technical University, 2009,28(2):189-191.
    [6] 李林. 鸡西煤田梨树煤矿地面煤层气抽采潜力[J]. 煤田地质与勘探,2017,45(1):67-70.

    LI Lin. CBM surface extraction potential in Lishu mine of Jixi coalfield[J]. Coal Geology & Exploration,2017,45(1):67-70.
    [7] 吴静. 焦坪矿区低阶煤储层因素对煤层气井产能的影响及敏感性分析[J]. 煤田地质与勘探,2015,43(5):44-48.

    WU Jing. Influence of reservoir factors on low-rank coalbed methane well production and sensitivity analysis[J]. Coal Geology & Exploration,2015,43(5):44-48.
    [8] 李晓龙. 鸡西矿区梨树煤矿瓦斯地面抽采井位部署及效果分析[D]. 西安:西安科技大学,2016.
    [9] 周加佳,姜在炳,李彬刚. 鸡西盆地煤层气资源开发潜力分析与评价[J]. 煤炭科学技术,2015,43(9):110-116.

    ZHOU Jiajia, JIANG Zaibing, LI Bingang. Analysis and evaluation on development potential of coalbed methane resources in Jixi basin[J]. Coal Science and Technology,2015, 43(9):110-116.
    [10] 韦重韬,秦勇,傅雪海. 煤层气储层数值模拟[M]. 北京:科学出版社,2015.
    [11] 王晓梅,张群,张培河,等. 煤层气井历史拟合方法探讨[J]. 煤田地质与勘探,2003,31(1):20-22.

    WANG Xiaomei,ZHANG Qun,ZHANG Peihe,et al. Discussion on historic fitting method of CBM well[J]. Coal Geology & Exploration,2003,31(1):20-22.
    [12] 倪小明,苏现波,张小东. 煤层气开发地质学[M]. 北京:化学工业出版社,2010.
    [13] 史进,吴晓东,韩国庆. 煤层气开发井网优化设计[J]. 煤田地质与勘探,2011,39(6):20-23.

    SHI Jin,WU Xiaodong,HAN Guoqing,et al. Optimization design of CBM well grid pattern[J]. Coal Geology & Exploration,2011,39(6):20-23.
    [14] 张培河,白建平. 煤矿区煤层气开发部署方法[J]. 煤田地质与勘探,2010,38(6):33-36.

    ZHANG Peihe,BAI Jianping. Method on well pattern arrangement of coalbed methane(CBM) development in coalmine area[J]. Coal Geology & Exploration,2010,38(6):33-36.
