ZDY1200L型履带式全液压坑道钻机的研制

基金项目:

煤炭科学研究总院西安研究院技术创新基金项目(2006XAYCX002)

详细信息

Development of the ZDY1200L track-mounted hydraulic tunnel drilling rig

摘要: 为适应当前煤矿井下小直径浅孔瓦斯抽放钻进的需要,研制了ZDY1200L型履带式全液压坑道钻机。钻机带有履带行走机构,机动性强;液压系统为开式循环双泵系统,采用负载敏感技术,降低系统功耗;具有可快速方便地调整钻孔方位角的转盘;自带电磁起动器及照明灯,使用方便,安全性强,便于钻孔作业和钻机维修。现场试验表明:该钻机操作简单,移动性好,钻进效率高,性能可靠,钻孔定位和稳固快捷方便。
- 履带钻机 /
- 负载敏感 /
- 转盘 /
- 瓦斯抽放
Abstract: To meet the requirement of small diameter and shallow hole drilling for gas drainage in coal tunnel,the ZDY1200L track-mounted hydraulic tunnel drilling rig has been developed.The track-mounted mechanism is used for high mobility,the load sensing technique is used in the open cycle double-pump hydraulic system to decrease the power wastage.The direction of drilling can be adjusted quickly and simply by the rotating table.The operation and maintenance are convenient with the electromagnetic starter and lamps.The field experiment shows that the rig has high operability,mobility,reliability and drilling efficiency,as well as the locating drilling direction and fixing the rig are very convenient.
- track-mounted drilling rig /
- load sensing /
- rotating table /
- gas drainage
