Characteristics and genetic mechanisms of geothermal reservoirs in the Neogene Guantao Formation, Qikou Sag
-
摘要: 渤海湾盆地黄骅坳陷歧口凹陷内赋存极为丰富的地热资源，其中新近系馆陶组热储最具开采价值，开展馆陶组热储地温场、孔渗条件、地热水循环规律和成因模式研究对认识馆陶组地热资源属性，合理开发地热资源具有重要意义。通过分析该区钻探、物探、测温、开发数据等资料，确定歧口凹陷内馆陶组热储为沉积盆地传导型地热系统，深部地幔热流和地壳内放射性生热以热传导方式传热，地热异常分布受基岩起伏的控制，在沧东断裂、北大港断裂带附近出现高温地热异常，地温梯度可达5.0℃/hm以上。馆陶组热储的孔渗条件南北两侧较高，中部较低，热储孔隙率整体在26%以上，渗透率在400×10-3 μm2以上，单井涌水量平均60 m3/h，是优质热储。地热水主要来源于古大气降水，由北部燕山补给，沿地层深循环，吸取岩石骨架热量，形成地热水。歧口凹陷区馆陶组热储地热资源量为41.81×1018 J，尤以天津滨海新区和河北黄骅市分布最广，占总资源量的95%，资源与需求匹配度高，具有良好的开发利用前景。Abstract: The Qikou Sag in the Huanghua Depression, Bohai Bay Basin boasts extremely abundant geothermal resources.Among them, the geothermal reservoirs of the Neogene Guantao Formation have the greatest potential for exploitation. To ascertain the properties of geothermal resources in this formation and rationally exploit these resources, it is significant to investigate the geothermal field, porosity, permeability, geothermal water circulation patterns, and genetic mode of geothermal reservoirs in the formation. Based on data from drilling, geophysical exploration, thermometry, and production of the study area, this study determined that the geothermal reservoirs of the Guantao Formation in the Qikou Sag constitute a conductive geothermal system of a sedimentary basin, with the heat flow from the deep mantle and the radioactive heat from the crust being transferred through heat conduction. The distribution of geothermal anomalies is subjected to wavy bedrock. Hightemperature geothermal anomalies with geothermal gradients up to above 5.0°C/hm are found near the Cangdong and Beidagang faults. The geothermal reservoirs of the Guantao Formation manifest high porosity and permeability in the north and south but low porosity and permeability in the central portion, with porosity greater than 26%, permeability above 400×10-3 μm2, and average single-well water yield of 60 m3/h overall. These suggest high-quality geothermal reservoirs. The geothermal water in the study area primarily originates from paleometeoric water. As the recharge source, the paleometeoric water from the Yanshan area in the north circulates deeply along strata while absorbing heat from the rock matrix, ultimately forming geothermal water. The geothermal reservoirs of the Guantao Formation in the Qikou Sag host geothermal resources of 41.81×1018 J, 95% of which are distributed in the Tianjin Binhai New Area and Huanghua City, Hebei Province. Their high match with demands makes geothermal resources in the study area have great potential for production and utilization.
-
-
[1] 国家能源局.国家能源局综合司关于公开征求《关于促进地热能开发利用的若干意见(征求意见稿)》意见的公告[EB/OL].(2021-04-14)[2022-05-01]. http://www.nea.gov.cn/202104/14/c_139880250.htm. [2] 汪集暘,庞忠和,程远志,等.全球地热能的开发利用现状与展望[J].科技导报, 2023, 41(12):5-11. WANG Jiyang, PANG Zhonghe, CHENG Yuanzhi, et al. Current state, utilization and prospective of global geothermal energy[J]. Science & Technology Review, 2023, 41(12):5-11.
[3] 杨吉龙,汪大明,牛文超,等.天津地热资源开发利用前景及存在问题[J].华北地质, 2022, 45(3):1-6. YANG Jilong, WANG Daming, NIU Wenchao, et al. Prospects and problems of geothermal resources exploitation and utilization in Tianjin[J]. North China Geology, 2022, 45(3):1-6.
[4] ZHENG Tingting, KANG Fengxin, ZHOU Qundao, et al. Key technologies on geothermal water reinjection of sandstone porous aquifers:A case study of Dezhou geothermal reservoir in northern China[J]. GRC Transactions, 2007, 41:2880-2895.
[5] 李珊,孙晓林,杨宝美,等.天津市新近系馆陶组砂岩热储回灌能力评价分析[J].华北地质, 2023, 46(2):38-44. LI Shan, SUN Xiaolin, YANG Baomei, et al. Evaluation and analysis of heat reservoir reinjection ability of Neogene Guantao Formation in Tianjin[J]. North China Geology, 2023, 46(2):38-44.
[6] 潘家明,眭彪,李耀义.天津滨海新区中新生态城地热资源赋存条件探讨[J].地质调查与研究, 2010, 33(3):185-189. PAN Jiaming, KUI Biao, LI Yaoyi. Discussion on the hosting conditions of geothermal resources in Sino-Singapore Tianjin Ecocity[J]. Geological Survey and Research, 2010, 33(3):185-189.
[7] 徐军祥,康凤新.山东省地热资源[M].北京:地质出版社, 2014. [8] 王连成.天津市新近系馆陶组地热流体回灌研究[D].北京:中国地质大学(北京), 2014. WANG Liancheng. A study of geothermal reinjection in the Guantao reservoir in Tianjin[D]. Beijing:China University of Geosciences (Beijing), 2014.
[9] 邓俊祖,蔺文静,邢林啸,等.冀中坳陷北部碳酸盐岩热储水化学特征及成因分析[J].地下水, 2022, 44(3):1-4. DENG Junzu, LIN Wenjing, XING Linxiao, et al. Chemical characteristics and genetic analysis of geothermal water in carbonate reservoir in the northern Jizhong Depression[J]. Groundwater, 2022, 44(3):1-4.
[10] 董月霞,黄红祥,任路,等.渤海湾盆地北部新近系馆陶组地热田特征及开发实践:以河北省唐山市曹妃甸地热供暖项目为例 [J].石油勘探与开发, 2021, 48(3):666-676. DONG Yuexia, HUANG Hongxiang, REN Lu, et al. Geology and development of geothermal field in Neogene Guantao Formation in northern Bohai Bay Basin:A case of the Caofeidian geothermal heating project in Tangshan, China[J]. Petroleum Exploration and Development, 2021, 48(3):666-676.
[11] 孙晓林,杨宝美,王震凯.天津地区奥陶系热储层上覆地层对其储层特征影响分析[J].华北地质, 2023, 46(2):31-37. SUN Xiaolin, YANG Baomei, WANG Zhenkai. Analysis of the influence of the overlying strata on the reservoir characteristics of the Ordovician thermal reservoir in Tianjin area[J]. North China Geology, 2023, 46(2):31-37.
[12] 刘杰,宋美钰,秦莉红,等.天津地区雾迷山组地热资源潜力区划[J].地质找矿论丛, 2019, 34(2):321-325. LIU Jie, SONG Meiyu, QIN Lihong, et al. Division of potential geothermal resources zones in the Wumishan Formation in Tianjin[J]. Contributions to Geology and Mineral Resources Research, 2019, 34(2):321-325.
[13] 魏真真,王丙贤,杨静.歧口凹陷断裂构造特征及其控油气作用[J].科学技术与工程, 2020, 20(11):4288-4295. WEI Zhenzhen, WANG Bingxian, YANG Jing. Structural characteristics of fault and its control on oil and gas distribution in Qikou Sag[J]. Science Technology and Engineering, 2020, 20(11): 4288-4295.
[14] 侯中帅,周立宏,金凤鸣,等.歧口凹陷热液流体活动及其对储集层的改造[J].地球科学, 2021, 46(1):200-214. HOU Zhongshuai, ZHOU Lihong, JIN Fengming, et al. Hydrothermal fluid activity and its reformation on reservoirs in Qikou Depression[J]. Earth Science, 2021, 46(1):200-214.
[15] 张雨健,王延斌.渤海湾盆地歧口凹陷滨海-港西断层垂向封堵性评价研究[J].矿业科学学报, 2022, 7(1):45-54. ZHANG Yujian, WANG Yanbin. Evaluation of vertical sealability of Binhai-Gangxi Fault in Qikou Sag Bohai Bay Basin[J]. Journal of Mining Science and Technology, 2022, 7(1):45-54.
[16] 史双双.歧口凹陷主断裂系统形成演化及油气地质意义[D].武汉:中国地质大学, 2009. SHI Shuangshuang. Formation and evolution for the main fault systems and their implication to petroleum geology in Qikou Depression[D]. Wuhan:China University of Geosciences, 2009.
[17] 周立宏,韩国猛,董越崎,等.渤海湾盆地歧口凹陷滨海断鼻断-砂组合模式与油气成藏[J].石油勘探与开发, 2019, 46(5): 869-882. ZHOU Lihong, HAN Guomeng, DONG Yueqi, et al. Fault-sand combination modes and hydrocarbon accumulation in Binhai Fault nose of Qikou Sag, Bohai Bay Basin, east China[J]. Petroleum Exploration and Development, 2019, 46(5):869-882.
[18] 吴永平,杨池银,王华,等.歧口凹陷构造-层序-沉积一体化研究及其应用[J].大地构造与成矿学, 2010, 34(4):451-460. WU Yongping, YANG Chiyin, WANG Hua, et al. Integrated study of tectonics-sequence stratrigraphy-sedimentology in the Qikou Sag and its applications[J]. Geotectonica et Metallogenia, 2010, 34(4): 451-460.
[19] 饶松,肖红平,王朱亭,等.渤海湾盆地馆陶组热储特征与地热资源评价[J].天然气工业, 2023, 43(5):141-152. RAO Song, XIAO Hongping, WANG Zhuting, et al. Geothermal reservoir characteristics and geothermal resource evaluation of Guantao Formation in the Bohai Bay Basin[J]. Natural Gas Industry, 2023, 43(5):141-152.
[20] 姜光政,高堋,饶松,等.中国大陆地区大地热流数据汇编(第四版)[J].地球物理学报, 2016, 59(8):2892-2910. JIANG Guangzheng, GAO Peng, RAO Song, et al. Compilation of heat flow data in the continental area of China (4th edition)[J]. Chinese Journal of Geophysics, 2016, 59(8):2892-2910.
[21] 刘杰.天津地区地热流体地球化学特征[D].北京:中国地质大学(北京), 2014. LIU Jie. The geochemical character of geothermal liquid in Tianjin area[D]. Beijing:China University of Geosciences (Beijing), 2014.
[22] JIANG Guangzheng, HU Shengbiao, SHI Yizuo, et al. Terrestrial heat flow of continental China:Updated dataset and tectonic implications[J]. Tectonophysics, 2019, 753:36-48.
[23] 唐永香,程万庆,赵苏民,等.天津滨海新区深部地热资源评价及有利勘探区圈定[J].中国地质调查, 2020, 7(4):37-42. TANG Yongxiang, CHENG Wanqing, ZHAO Sumin, et al. Evaluation of deep geothermal resources and delineation of favorable exploration areas in Binhai New Area, Tianjin[J]. Geological Survey of China, 2020, 7 [24] 刘祥柏,柳广弟,宋泽章,等.渤海湾盆地歧口凹陷沙河街组烃源岩沉积环境及形成机理[J].天然气地球科学, 2022, 33(12): 2008-2031. LIU Xiangbai, LIU Guangdi, SONG Zezhang, et al. The paleo-sedimentary environment and formation mechanism of the source rocks in Shahejie Formation, Qikou Sag, Bohai Bay Basin[J]. Natural Gas Geoscience, 2022, 33(12):2008-2031.
[25] 高新智.天津市孔隙型砂岩热储回灌能力评价模型研究[D].北京:中国地质大学(北京), 2018. GAO Xinzhi. The model of thermal storage recharge capacity for sandstone pore in Tianjin[D]. Beijing:China University of Geosciences (Beijing), 2018.
[26] 赵苏民.沉积盆地型地热田勘查开发与利用[M].北京:地质出版社, 2013. [27] 王贵玲,蔺文静,刘峰,等.地热系统深部热能聚敛理论及勘查实践[J].地质学报, 2023, 97(3):639-660. WANG Guiling, LIN Wenjing, LIU Feng, et al. Theory and survey practice of deep heat accumulation in geothermal system and exploration practice[J]. Acta Geologica Sinica, 2023, 97(3):639-660.
[28] 高宝珠,王心义,曾梅香,等.天津市地下热水成因、年龄及补给条件研究报告[R].天津:天津地热勘查开发设计院, 2013. [29] 龚育龄.中国东部渤海湾盆地热结构和热演化[D].南京:南京大学, 2003. GONG Yuling. Thermal structure and thermal evolution in the Bohai Bay Basin in eastern China[D]. Nanjing:Nanjing University, 2003.
[30] 左银辉,邱楠生,常健,等.渤海湾盆地中、新生代岩石圈热结构研究[J].地质学报, 2013, 87(2):145-153. ZUO Yinhui, QIU Nansheng, CHANG Jian, et al. Meso-Cenozoic lithospheric thermal structure in the Bohai Bay Basin[J]. Acta Geologica Sinica, 2013, 87(2):145-153.
[31] 张百鸣,林黎,赵苏民.天津地区地热形成机理分析[J].水文地质工程地质, 2006(2):104-107. ZHANG Baiming, LIN Li, ZHAO Sumin. Analyses on mechanism of geothermal origin in Tianjin area[J]. Hydrogeology & Engineering Geology, 2006(2):104-107.
[32] 郭飒飒,朱传庆,邱楠生,等.雄安新区深部地热资源形成条件与有利区预测[J].地质学报, 2020, 94(7):2026-2035. GUO Sasa, ZHU Chuanqing, QIU Nansheng, et al. Formation conditions and favorable areas for the deep geothermal resources in the Xiong'an New Area[J]. Acta Geologica Sinica, 2020, 94(7):2026-2035.
[33] 王贵玲,蔺文静.我国主要水热型地热系统形成机制与成因模式[J].地质学报, 2020, 94(7):1923-1937. WANG Guiling, LIN Wenjing. Main hydro-geothermal systems and their genetic models in China[J]. Acta Geologica Sinica, 2020, 94(7): 1923-1937.
[34] 王贵玲,张薇,蔺文静,等.京津冀地区地热资源成藏模式与潜力研究[J].中国地质, 2017, 44(6):1074-1085. WANG Guiling, ZHANG Wei, LIN Wenjing, et al. Research on formation mode and development potential of geothermal resources in Beijing-Tianjin-Hebei region[J]. Geology in China, 2017, 44(6): 1074-1085.
