矿井水情监测与水害风险预警平台设计与实现

连会青, 徐斌, 田振焘, 刘德民, 杨艺, 潘光义, 王瑞

连会青, 徐斌, 田振焘, 刘德民, 杨艺, 潘光义, 王瑞. 矿井水情监测与水害风险预警平台设计与实现[J]. 煤田地质与勘探, 2021, 49(1): 198-207. DOI: 10.3969/j.issn.1001-1986.2021.01.021
引用本文: 连会青, 徐斌, 田振焘, 刘德民, 杨艺, 潘光义, 王瑞. 矿井水情监测与水害风险预警平台设计与实现[J]. 煤田地质与勘探, 2021, 49(1): 198-207. DOI: 10.3969/j.issn.1001-1986.2021.01.021
LIAN Huiqing, XU Bin, TIAN Zhentao, LIU Demin, YANG Yi, PAN Guangyi, WANG Rui. Design and implementation of mine water hazard monitoring and early warning platform[J]. COAL GEOLOGY & EXPLORATION, 2021, 49(1): 198-207. DOI: 10.3969/j.issn.1001-1986.2021.01.021
Citation: LIAN Huiqing, XU Bin, TIAN Zhentao, LIU Demin, YANG Yi, PAN Guangyi, WANG Rui. Design and implementation of mine water hazard monitoring and early warning platform[J]. COAL GEOLOGY & EXPLORATION, 2021, 49(1): 198-207. DOI: 10.3969/j.issn.1001-1986.2021.01.021



矿井水情监测与水害风险预警平台设计与实现

基金项目:

国家重大研发计划课题(2017YFC0804108);国家自然科学基金项目(51774136);河北省自然科学基金重点项目(D2017508099)

详细信息
    作者简介:

    连会青,1975年生,女,山西忻州人,博士,教授,从事矿井水害防治工作.E-mail:2366884370@qq.com

    通讯作者:

    徐斌,1988年生,男,湖南邵阳人,博士,讲师,从事地质灾害及其防治对策研究工作.E-mail:jinzigaofeng@126.com

  • 中图分类号: TD745

Design and implementation of mine water hazard monitoring and early warning platform

  • 摘要: 任何矿井水害事故均会显现不同的预兆,为夯实水害智能预警基础,明晰了感知、辨识、评估、预测及相互逻辑关系的系统建设内涵,针对不同水害类型,根据其突水机理不同,设计三大类多模式水害典型场景,建立相应突水判据,提出了确定性理论精确预测与包括大数据及深度学习在内的非确定性趋势推测两类预测方法,为智能预警系统的预测预报、预警准则及阈值设置奠定理论基础。以陕西省彬长矿区亭南矿为例,建立了动态信息、静态信息及关联信息的指标体系,将地面水文动态监测单元、井下水情环境监测单元以及采掘工作面采动动态监测单元集成,构建原位采集和突水要素预兆感知系统,实施基于关键层电性参数动态监测、关键部位单点或多点多参数监测联合布置的突水前兆信息精准获取方案,采用确定性模拟模型和非确定性智能模型,实现水害预测预警功能,基于多源数据融合和空间联动分析技术,预警系统实现了井上下全空间水害风险预警“一张图”的可视化展示。实践表明,监测预警平台理论基础扎实,预测预警效果显著。
    Abstract: Any mine water hazard will show different omens. In order to consolidate the foundation of intelligent early warning of water disaster, the connotation of system construction of perception, identification, evaluation, prediction and the interlogical relation are clarified. The mechanism of water inrush is varred for different types of water hazards, we designed three types of multi-mode water inrush typical scenarios and established the corresponding water inrush criteria. In addition, so we proposed two kinds of forecasting methods, namely the precise prediction of deterministic theory and the non-deterministic trend projections including big data and deep learning, which laid a solid theoretical foundation for the prediction, warning criteria and threshold setting of the intelligent early warning system. Taking Tingnan Coal Mine of Binchang mining area in Shaanxi Province as an example, we established an index system of dynamic information, static information and related information, which integrated the ground hydrological dynamic monitoring unit, underground hydrological environment monitoring unit and mining dynamic monitoring unit of mining face, and built an in-situ acquisition and water-inrush element prediction perception system. Based on the dynamic monitoring of electrical parameters of key layers and the joint arrangement of single point or multi-point and multi-parameter monitoring of key parts, the accurate acquisition scheme of water inrush precursor information was implemented. The deterministic simulation model and the non-deterministic intelligent model were adopted to realize the prediction and early warning function of water disasters. According to the multi-source data fusion and spatial linkage analysis technology, the early warning system realized the visual display of "one map" of the whole space water disaster early warning on surface and underground. The results prove that the monitoring and early warning platform has a solid theoretical foundation, and the prediction and early warning effect is remarkable.
  • [1] 虎维岳. 矿山水害防治理论与方法[M]. 北京:煤炭工业出版社,2005.

    HU Weiyue. Theory and method of mine water disaster control[M]. Beijing:China Coal Industry Publishing House,2005.

    [2] 李振栓,尹尚先,马积福. 煤矿水情监测预警保障系统[M]. 太原:山西人民出版社,2014.

    LI Zhenshuan,YIN Shangxian,MA Jifu. Coal mine water monitoring and early warning system[M]. Taiyuan:Shanxi People's Publishing House,2014.

    [3] 乔伟,靳德武,王皓,等. 基于云服务的煤矿水害监测大数据智能预警平台构建[J]. 煤炭学报,2020,45(7):2619-2627.

    QIAO Wei,JIN Dewu,WANG Hao,et al. Development of big data intelligent early warning platform for coal mine water hazard monitoring based on cloud service[J]. Journal of China Coal Society,2020,45(7):2619-2627.

    [4] 尹尚先. 煤层底板突水模式及机理研究[J]. 西安科技大学学报,2009,29(6):661-665.

    YIN Shangxian. Modes and mechanism for water inrushes from coal seam floor[J]. Journal of Xi'an University of Science and Technology,2009,29(6):661-665.

    [5]

    JIN Dewu,ZHENG Gang,LIU Zaibin,et al. Real-time monitoring and early warning techniques of water inrush through coal floor[J]. Procedia Earth and Planetary Science,2011,3:37-46.

    [6]

    GE Maochen. Efficient mine microseismic monitoring[J]. International Journal of Coal Geology,2005,64(1/2):44-56.

    [7]

    HARTEIS S P,DOLINAR D R. Water and slurry bulkheads in underground coal mines:Design,monitoring and safety concerns[J]. Mining Engineering,2006,58(12):41-47.

    [8] 胡耀青,赵阳升,杨栋,等. 承压水上采煤突水的区域监控理论与方法[J]. 煤炭学报,2000,25(3):252-255.

    HU Yaoqing,ZHAO Yangsheng,YANG Dong,et al. The Regional monitor theory and method of water-outburst for coal mining over confined aquifer[J]. Journal of China Coal Society,2000,25(3):252-255.

    [9] 武强,解淑寒,裴振江,等. 煤层底板突水评价的新型实用方法Ⅲ:基于GIS的ANN型脆弱性指数法应用[J]. 煤炭学报,2007,32(12):1301-1306.

    WU Qiang,XIE Shuhan,PEI Zhenjiang,et al. A new practical methodology of the coal floor water bursting evaluating Ⅲ:The application of ANN vulnerable index method based on GIS[J]. Journal of China Coal Society,2007,32(12):1301-1306.

    [10] 杨天鸿,唐春安,谭志宏,等. 岩体破坏突水模型研究现状及突水预测预报研究发展趋势[J]. 岩石力学与工程学报,2007,26(2):268-277.

    YANG Tianhong,TANG Chun'an,TAN Zhihong,et al. State of the art of inrush models in rock mass failure and developing trend for prediction and forecast of groundwater inrush[J]. Chinese Journal of Rock Mechanics and Engineering,2007,26(2):268-277.

    [11] 靳德武,刘英锋,冯宏,等. 煤层底板突水监测预警系统的开发及应用[J]. 煤炭科学技术,2011,39(11):14-17.

    JIN Dewu,LIU Yingfeng,FENG Hong,et al. Development and application of monitoring and early warning system to seam floor water inrush[J]. Coal Science and Technology,2011,39(11):14-17.

    [12] 靳德武,赵春虎,段建华,等. 煤层底板水害三维监测与智能预警系统研究[J]. 煤炭学报,2020,45(6):2256-2264.

    JIN Dewu,ZHAO Chunhu,DUAN Jianhua,et al. Research on 3D monitoring and intelligent early warning system for water hazard of coal seam floor[J]. Journal of China Coal Society,2020,45(6):2256-2264.

    [13] 赵春虎. 孤岛工作面底板破坏深度微震测试与模拟分析[J]. 煤田地质与勘探,2019,47(4):110-116.

    ZHAO Chunhu. Microseismic test and numerical simulation analysis of floor failure depth of isolated coal mining face[J]. Coal Geology & Exploration,2019,47(4):110-116.

    [14] 姜福兴,叶根喜,王存文,等. 高精度微震监测技术在煤矿突水监测中的应用[J]. 岩石力学与工程学报,2008,27(9):1932-1938.

    JIANG Fuxing,YE Genxi,WANG Cunwen,et al. Application of high-precision microseismic monitoring technique to water inrush monitoring in coal mine[J]. Chinese Journal of Rock Mechanics and Engineering,2008,27(9):1932-1938.

    [15] 王经明,董书宁,刘其声. 煤矿突水灾害的预警原理及其应用[J]. 煤田地质与勘探,2005,33(增刊1):1-4.

    WANG Jingming,DONG Shuning,LIU Qisheng. The principal of early warning for groundwater hazards in coal mine and its application[J]. Coal Geology & Exploration,2005,33(Sup.1):1-4.

    [16] 尹尚先,王经明,梁育龙,等. 矿井突水灾害监测预警系统及其控制方法:CN101526010[P]. 2009-09-09.

    YIN Shangxian,WANG Jingming,LIANG Yulong,et al. Mine water inrush disaster monitoring and early warning system and its control method:CN101526010[P]. 2009-09-09.

    [17] 刘德民,尹尚先,连会青. 煤矿工作面底板突水灾害预警重点监测区域评价技术[J]. 煤田地质与勘探,2019,47(5):9-15.

    LIU Demin,YIN Shangxian,LIAN Huiqing. Evaluation technology for key monitoring area of early warning of water inrush from the floor of working face in coal mine[J]. Coal Geology & Exploration,2019,47(5):9-15.

    [18] 刘德民,尹尚先,连会青,等. 煤矿底板突水定量预警准则及预警系统研究[J]. 煤炭工程,2019,51(4):16-20.

    LIU Demin,YIN Shangxian,LIAN Huiqing,et al. Study on quantitative warning criteria and early warning system for water inrush from coal floor[J]. Coal Engineering,2019,51(4):16-20.

    [19] 张碧云,刘王梅,程俊文,等. 聚类分析和主成分分析法研究桑黄气相色谱-质谱指纹图谱[J]. 食品与发酵科技,2020,56(4):91-97.

    ZHANG Biyun,LIU Wangmei,CHENG Junwen,et al. Cluster analysis and principal component analysis were used to study the chromatography-mass spectrometry fingerprints of Sanghuangporus sanghuang[J]. Food and Fermentation Sciences & Technology,2020,56(4):91-97.

    [20] 李艳双,曾珍香,张闽,等. 主成分分析法在多指标综合评价方法中的应用[J]. 河北工业大学学报,1999,28(1):96-99.

    LI Yanshuang,ZENG Zhenxiang,ZHANG Min,et al. Application of primary component analysis in the methods of comprehensive evaluation for many indexes[J]. Journal of Hebei University of Technology,1999,28(1):96-99.

    [21] 尹尚先,武强. 陷落柱概化模式及突水力学判据[J]. 北京科技大学学报,2006,28(9):812-817.

    YIN Shangxian,WU Qiang. Generalized modes and academic criterions of water inrush from paleo-sinkholes[J]. Journal of University of Science and Technology Beijing,2006,28(9):812-817.

    [22] 刘德民. 华北型煤田矿井突水机理及预警技术:以赵庄矿为例[D]. 北京:中国矿业大学(北京),2015. LIU Demin. Mechanism of water-inrush and early warning technology in North-China-Type coalfield:A case study of Zhaozhuang Mine[D]. Beijing:China University of Mining & Technology(Beijing),2015.
    [23] 王苗. 基于灰色理论的矿井顶板涌水量预测模型的建立与应用[D]. 青岛:山东科技大学,2007.

    WANG Miao. Study on forecast model of mine roof water inrush based on grey system[D]. Qingdao:Shandong University of Science and Technology,2007.

    [24] 尹尚先,徐斌,刘德民,等. 我国华北煤田岩溶陷落柱预测研究[J]. 煤炭科学技术,2016,44(1):172-177.

    YIN Shangxian,XU Bin,LIU Demin,et al. Study on location prediction of paleo-karst sinkholes in northern China coalfields[J]. Coal Science and Technology,2016,44(1):172-177.

    [25] 范高锋,王伟胜,刘纯,等. 基于人工神经网络的风电功率预测[J]. 中国电机工程学报,2008,28(34):118-123.

    FAN Gaofeng,WANG Weisheng,LIU Chun,et al. Wind power prediction based on artificial neural network[J]. Proceedings of The CSEE,2008,28(34):118-123.

    [26] 邓卫军. 基于深度学习的计算机图形描述算法研究[J]. 微型电脑应用,2021,37(2):53-55.

    DENG Weijun. Research on computer graphics description algorithm based on deep learning[J]. Microcomputer Applications,2021,37(2):53-55.

    [27] 郑纲. 煤矿底板突水机理与底板突水实时监测技术研究[D]. 西安:长安大学,2004.

    ZHENG Gang. The floor water bursting mechanism analysis of floor water bursting in coal mines and research on floor water bursting monitoring technique[D]. Xi'an:Chang'an University,2004.

  • 期刊类型引用(25)

    1. 王博睿,张远航. 含隐伏断层底板原生缺陷致灾前兆研究. 煤炭技术. 2025(01): 216-220 . 百度学术
    2. 张雪莲. 潞安矿区矿井水害及防治措施分析. 华北自然资源. 2025(01): 14-16+20 . 百度学术
    3. 连会青,晏涛,尹尚先,徐斌,康佳,周旺,闫国成. 基于透明水文地质模型的工作面顶板水害预警研究. 煤炭科学技术. 2025(01): 259-271 . 百度学术
    4. 牛亚豪,王畅,刘佳佳. 基于高精度差分定位法的水文测量自动化报警系统设计. 自动化与仪器仪表. 2024(01): 231-234 . 百度学术
    5. 苏雄,李小龙,贺杰伟. 基于三维GIS的煤矿数据集成自动化监测系统. 自动化与仪表. 2024(03): 121-125 . 百度学术
    6. 郝宪杰,李航,赵毅鑫,杨怀翔,杨波,刘科峰,李宜家. 基于日累积微震指标与水位关联效应的底板突水预警方法与应用. 岩石力学与工程学报. 2024(09): 2125-2139 . 百度学术
    7. 曾一凡,于超,武强,赵菱尔,尹尚先,张博成,刘泽洋,崔雅帅,阚雪冬,黄浩. 煤矿防治水“三区”划分方法及其水害防治意义. 煤炭学报. 2024(08): 3605-3618 . 百度学术
    8. 宗伟琴. 煤矿水害监测预警GIS平台研发及应用. 能源科技. 2024(05): 28-33 . 百度学术
    9. 姚有利,寇杰,张孟浩. 基于博弈论组合赋权-TOPSIS的煤矿“一通三防”风险评估. 矿业安全与环保. 2024(06): 71-78 . 百度学术
    10. 赵群,郝韶嵩. 水害风险预警系统在皖北煤电集团的设计研究. 煤炭与化工. 2023(02): 33-37 . 百度学术
    11. 丁莹莹,卜昌森,连会青,尹尚先,徐斌,张丐卓,姚辉,董其金. 基于仿真平台的矿井突水淹没路径和逃生路径规划. 煤矿安全. 2023(05): 20-26 . 百度学术
    12. 董书宁. 人工智能技术在煤矿水害防治智能化发展中的应用. 煤矿安全. 2023(05): 1-12 . 百度学术
    13. 袁利伟,龙皓楠,李斌,李延林,曹浪,辛岩. 基于HMM算法的矿山水灾害链复杂演化网络模型构建及应用. 化工矿物与加工. 2023(08): 47-55 . 百度学术
    14. 曾一凡,武强,赵苏启,苗耀武,张晔,梅傲霜,孟世豪,刘晓秀. 我国煤矿水害事故特征、致因与防治对策. 煤炭科学技术. 2023(07): 1-14 . 百度学术
    15. 尹尚先,徐斌,尹慧超,曹敏,丁莹莹,梁满玉. 矿井水防治学科基本架构及内涵. 煤炭科学技术. 2023(07): 24-35 . 百度学术
    16. 邱浩,李宏杰,李文,李江华,杜明泽,姜鹏. 煤矿水害智能预警系统关键架构及模型研究. 煤炭科学技术. 2023(07): 197-206 . 百度学术
    17. 李鑫,孙亚军,徐智敏,陈歌. 矿山采动突水危险源划分与致灾危险性评价研究. 煤炭工程. 2023(09): 108-115 . 百度学术
    18. 张党育,武斌,贾靖,赵立松,李玉宝. 基于微震数据及模型的煤矿水害“双驱动”预警体系构建与应用. 煤炭科学技术. 2023(S1): 242-255 . 百度学术
    19. 张志武. 高密度电阻率法在承压水导升高度探测中的应用. 煤. 2022(06): 71-72+95 . 百度学术
    20. 宋容. 基于多层关联规则算法的煤矿突出预警模型. 能源与环保. 2022(06): 300-305 . 百度学术
    21. 许进鹏,周宇,浦早红,庞思远. 离层积水量估算方法及离层突水预测——以陕西招贤煤矿1304工作面突水为例. 煤炭学报. 2022(08): 3083-3090 . 百度学术
    22. 张辰宇. 基于5G通信技术的矿井开采工作面环境监测系统. 能源与环保. 2022(11): 220-225 . 百度学术
    23. 卓聪志. 首采区域内上覆含水层的富水特征及采区涌水量计算. 山西化工. 2022(07): 112-114 . 百度学术
    24. 隋旺华. 矿山安全地质学:综述. 工程地质学报. 2021(04): 901-916 . 百度学术
    25. 薛峰峰. 低位岩巷穿层探放技术在采空区水害治理中的应用. 陕西煤炭. 2021(05): 155-158 . 百度学术

    其他类型引用(9)
