红山煤矿石门揭突出煤层综合防突技术

汪北方, 梁冰, 张晶, 迟海波, 黄普江

汪北方, 梁冰, 张晶, 迟海波, 黄普江. 红山煤矿石门揭突出煤层综合防突技术[J]. 煤田地质与勘探, 2019, 47(5): 86-93. DOI: 10.3969/j.issn.1001-1986.2019.05.012
引用本文: 汪北方, 梁冰, 张晶, 迟海波, 黄普江. 红山煤矿石门揭突出煤层综合防突技术[J]. 煤田地质与勘探, 2019, 47(5): 86-93. DOI: 10.3969/j.issn.1001-1986.2019.05.012
shu
WANG Beifang, LIANG Bing, ZHANG Jing, CHI Haibo, HUANG Pujiang. Comprehensive outburst prevention technology of outburst-prone coal seam uncovered by crossdrift in Hongshan coal mine[J]. COAL GEOLOGY & EXPLORATION, 2019, 47(5): 86-93. DOI: 10.3969/j.issn.1001-1986.2019.05.012
Citation: WANG Beifang, LIANG Bing, ZHANG Jing, CHI Haibo, HUANG Pujiang. Comprehensive outburst prevention technology of outburst-prone coal seam uncovered by crossdrift in Hongshan coal mine[J]. COAL GEOLOGY & EXPLORATION, 2019, 47(5): 86-93. DOI: 10.3969/j.issn.1001-1986.2019.05.012
shu



红山煤矿石门揭突出煤层综合防突技术

  • 1. 辽宁工程技术大学矿业学院，辽宁 阜新 123000;

  • 2. 煤炭资源与安全开采国家重点实验室，江苏 徐州 221008;

  • 3. 煤炭开采水资源保护与利用国家重点实验室，北京 100011;

  • 4. 辽宁工程技术大学力学与工程学院，辽宁 阜新 123000;

  • 5. 辽宁工程技术大学理学学院，辽宁 阜新 123000

基金项目:

国家自然科学基金项目（51704139）；煤炭资源与安全开采国家重点实验室开放研究基金项目（SKLCRSM18KF011）；煤炭开采水资源保护与利用国家重点实验室开放研究基金项目（SHJT-17-42.7）

详细信息
    作者简介:

    汪北方,男,1988年生,黑龙江抚远人,博士,从事矿井开采理论与技术研究工作.E-mail:wang_beifang@126.com

  • 中图分类号: TD713

Comprehensive outburst prevention technology of outburst-prone coal seam uncovered by crossdrift in Hongshan coal mine

  • 1. School of Mines, Liaoning Technical University, Fuxin 123000, China;

  • 2. State Key Laboratory of Coal Resources and Safe Mining, Xuzhou 221008, China;

  • 3. State Key Laboratory of Water Resource Protection and Utilization in Coal Mining, Beijing 100011, China;

  • 4. School of Mechanics and Engineering, Liaoning Technical University, Fuxin 123000, China;

  • 5. School of Science, Liaoning Technical University, Fuxin 123000, China

Funds:

National Natural Science Foundation of China(51704139)

摘要

    摘要
  • 摘要: 煤矿井下石门揭煤诱发的煤与瓦斯突出是一种十分复杂的矿井地质动力灾害，严重威胁着煤矿安全高效生产。选取辽宁红山煤矿为工程背景，运用FLAC3D模拟分析矿井南翼瓦斯突出危险区石门揭12煤过程中围岩力学响应特征，揭示石门揭煤突出机理，提出瓦斯预抽措施配以改进金属骨架的综合防突技术方案。研究结果表明：石门揭12煤期间，工作面超前支承压力随石门掘进动态前移，距煤层6 m范围内，工作面前方围岩掘进扰动强烈，煤体出现明显应力集中现象，垂直应力为15~19 MPa，已超过煤体强度。同时，石门工作面围岩变形量急剧增大，顶板下沉位移为15~92.22 cm，煤体弹性变形能积聚；工作面围岩塑性区范围也迅速扩展，在石门中线垂直剖面上的面积为10~50 m2，裂纹贯通形成碎煤射流通道。综合模拟结果可知，石门揭12煤过程中煤体承载较高集中应力和瓦斯压力，且储存大量弹性变形能，极易诱发突出。基于此，在传统瓦斯预抽防突措施的基础上，对现有金属骨架防突技术进行改进，使其同时具备瓦斯预抽、煤体固化和超前支护的综合防突作用，并通过现场应用取得了良好效果，为类似条件石门揭煤防突研究提供重要借鉴和参考。
    Abstract: Coal and gas outburst is a complex geo-dynamic disaster induced by a coal seam uncovered by crossdrift, threatens the safety and efficient production of coal mines seriously. For this, Hongshan coal mine was selected as engineering background to simulate mechanical response characteristics of surrounding rock during uncovering No.12 coal seam in a gas bursting hazardous zone with FLAC3D software. Then the outburst mechanism during uncovering a coal seam by a crossdrift was revealed, and comprehensive outburst prevention technology combining mine gas pre-drainage and improved metal skeleton was put forward. The results showed that the abutment pressure ahead of the working face moved forward dynamically with crossdrift advance, within the range of 6 m from No.12 coal seam, excavation disturbance of surrounding rock in front of the working face was strong, and there was an obvious stress concentration phenomenon in the coal seam, where vertical stress was 1.25-1.58, which had exceeded the coal strength. Meanwhile, surrounding rock deformation increased sharply, roof subsidence displacement was 15~92.22 cm, so that coal elastic deformation energy was accumulated. Certainly, surrounding rock plastic zone also expanded rapidly, and the area on the crossdrift midline vertical section was 10~50 m2, until cracks completely penetrated and formed jet channels for crushing coal. So in the process of uncovering No.12 coal seam by a crossdrift, the coal seam was under high concentrated stress and gas pressure, and stored great deal of elastic deformation energy, which easily induced coal and gas outburst. Above all, on the basis of using traditional outburst prevention measures with mine gas pre-drainage, the existing outburst prevention technique of metal skeleton was improved, which had a comprehensive outburst prevention effect, such as gas pre-drainage, coal solidification and advance support. And this was applied to prevent outburst at the site and obtained good effect, provided important reference for outburst prevention when coal seam was uncovered by a crossdrift under the similar conditions.
    • HTML全文
    • 参考文献(19)
  • [1] 杨威,林柏泉,吴海进,等."强弱强"结构石门揭煤消突机理研究[J]. 中国矿业大学学报,2011,40(4):517-522.

    YANG Wei,LIN Baiquan,WU Haijin,et al. Mechanism study of the "strong soft strong" structure for cross cut in uncovering a coal seam[J]. Journal of China University of Mining & Technology,2011,40(4):517-522.
    [2] 张超林,许江,彭守建,等. 煤与瓦斯突出物理模拟实验研究进展及展望[J]. 煤田地质与勘探,2018,46(4):28-34.

    ZHANG Chaolin,XU Jiang,PENG Shoujian,et al. Advances and prospects in physical simulation of coal and gas outburst[J]. Coal Geology & Exploration,2018,46(4):28-34.
    [3] 田世祥. 石门揭煤防突效果快速检验的原理及方法研究[D].徐州:中国矿业大学,2016.
    [4] 王刚,程卫民,张清涛,等. 石门揭煤突出模拟实验台的设计与应用[J]. 岩土力学,2013,34(4):1202-1210.

    WANG Gang,CHENG Weimin,ZHANG Qingtao,et al. Design of simulation experiment and its application system of outburst in uncovering coal seam in cross-cut[J]. Rock and Soil Mechanics,2013,34(4):1202-1210.
    [5] 史中刚. 涌山石门揭煤突岀主要影响因素及防治措施研究[D].阜新:辽宁工程技术大学,2013.
    [6] 于不凡,王佑安. 煤矿瓦斯灾害防治及利用技术手册[M]. 北京:煤炭工业出版社,2002.
    [7] 梁冰,章梦涛,潘一山,等. 煤和瓦斯突出的固流耦合失稳理论[J]. 煤炭学报,1995,20(5):492-496.

    LIANG Bing,ZHANG Mengtao,PAN Yishan,et al. Theory of instability of flow fixation coupling for coal and gas outburst[J]. Journal of China Coal Society,1995,20(5):492-496.
    [8] 高魁,刘泽功,刘健. 地应力在石门揭构造软煤诱发煤与瓦斯突出中的作用[J]. 岩石力学与工程学报,2015,34(2):305-312.

    GAO Kui,LIU Zegong,LIU Jian. Effect of geostress on coal and gas outburst in the uncovering tectonic soft coal by cross-cut[J]. Chinese Journal of Rock Mechanics and Engi-neering,2015,34(2):305-312.
    [9] 魏建平,宋会磊,刘勇,等. 石门揭煤高角度断层围岩注浆加固理论研究与应用[J]. 安全与环境,2015,15(3):129-131.

    WEI Jianping,SONG Huilei,LIU Yong,et al. Research and application of the grouting reinforcement theory to the cross-cut coal-seam surrounding faults at a high angle[J]. Journal of Safety and Environment,2015,15(3):129-131.
    [10] 刘震,李增华,杨永良,等. 石门揭煤区域防突岩巷卸压消突作用[J]. 采矿与安全工程学报,2013,30(6):940-945.

    LIU Zhen,LI Zenghua,YANG Yongliang,et al. Pressure relief and outburst elimination effect of outburst prevention rock tunnel in rock cross-cut coal uncovering region[J]. Journal of Mining & Safety Engineering,2013,30(6):940-945.
    [11] 郭运华,朱维申,李新平,等. 基于FLAC3D改进的初始地应力场回归方法[J]. 岩土工程学报,2014,36(5):892-898.

    GUO Yunhua,ZHU Weishen,LI Xinping,et al. Improved regression method for initial geostress based on FLAC3D[J]. Chinese Journal of Geotechnical Engineering,2014,36(5):892-898.
    [12] 李为腾,杨宁,李廷春,等. FLAC3D中锚杆破断失效的实现及应用[J]. 岩石力学与工程学报,2016,35(4):753-767.

    LI Weiteng,YANG Ning,LI Tingchun,et al. Implementation of bolt broken failure in FLAC3D and its application[J]. Chinese Journal of Rock Mechanics and Engineering,2016,35(4):753-767.
    [13] 刘最亮,冯梅梅. 阳泉矿区新景矿构造煤发育规律的数值模拟[J]. 煤田地质与勘探,2018,46(4):35-43.

    LIU Zuiliang,FENG Meimei. Numerical simulation study on the development patterns of tectonically deformed coal in Xinjing coal mine in Yangquan[J]. Coal Geology & Exploration,2018,46(4):35-43.
    [14] 韩万东,石健. 涌山矿石门揭煤地应力数值模拟[J]. 辽宁工程技术大学学报(自然科学版),2016,35(5):464-468.

    HAN Wandong,SHI Jian. Cross-hole exposing coal numerical simulation based on Yongshan mine[J]. Journal of Liaoning Technical University(Natural Science),2016,35(5):464-468.
    [15] 杨永杰,宋扬,陈绍杰,等. 煤岩强度离散性及三轴压缩试验研究[J]. 岩土力学,2006,27(10):1763-1766.

    YANG Yongjie,SONG Yang,CHEN Shaojie,et al. Experimental study on strength discreteness and triaxial compression of coal[J]. Rock and Soil Mechanics,2006,27(10):1763-1766.
    [16] 冯涛,谢雄刚,刘辉,等. 注液冻结法在石门揭煤中防突作用的可行性研究[J]. 煤炭学报,2010,35(6):937-941.

    FENG Tao,XIE Xionggang,LIU Hui,et al. Research on feasibility in preventing the coal seam in cross-cut[J]. Journal of China Coal Society,2010,35(6):937-941.
    [17] 李浩,石必明,李耀. 强突松软近距离煤层群石门揭煤防突技术研究[J]. 中国安全生产科学技术,2014,10(1):98-102.

    LI Hao,SHI Biming,LI Yao. Study on technologies of rock cross-cut coal uncovering and avoiding outburst of gas in condition of soft coal seams with strong gas outburst risk in short distance[J]. Journal of Safety Science and Technology,2014,10(1):98-102.
    [18] 杨凯,李绍泉,吴桂义. 高压水割缝增透防突技术在运输石门揭煤中的应用[J]. 煤炭技术,2011,30(7):81-82.

    YANG Kai,LI Shaoquan,WU Guiyi. Application of high-pressure water cut outburst-proof technology in exposing coal at transport cross-cut[J]. Coal Technology,2011,30(7):81-82.
    [19] 俞启香. 矿井瓦斯防治[M]. 徐州:中国矿业大学出版社,1992.
