摘要: 为解决山西某矿区煤层气钻孔漏失问题，选择合适的堵漏浆液。基于正交试验的设计方法，以低水解聚丙烯酰胺（PHP）、801堵漏剂、水玻璃和植物胶为堵漏材料制成堵漏浆液，测试了堵漏浆液的相对密度、失水量、塑性黏度、表观黏度、和动切力等指标，并采用极差法与方差法分析了各材料（因素）的显著性。研究表明：塑性黏度、表观黏度受PHP的影响最大，水玻璃对失水量影响最大，801堵漏剂对动切力影响最大。以较大的黏度和动切力及较低的失水量为评价依据，确定了堵漏浆液的最优配方。建立了最优配方堵漏浆液的流变方程，模拟试验测定堵漏浆液的堵漏性能，并通过4个煤层气钻孔工程实践验证了堵漏浆液的堵漏功效。Abstract: In order to solve the problem of leakage of coalbed methane wells in a mining area in Shanxi, through choosing suitable plugging slurry, using PHP, 801 plugging agent, water glass and vegetable gum as plugging materials, the index of plugging slurry was measured including specific gravity, water loss, plastic viscosity, apparent viscosity, and dynamic shear force. The significance of each material(factor)was analyzed by range analysis and variance analysis. The results showed that the plastic viscosity and apparent viscosity were most affected by PHP; water glass had the greatest impact on the water loss time; the 801 plugging agent had the greatest impact on the dynamic shear force. The optimum formulation of plugging slurry was determined with larger viscosity, larger shear force and lower water loss. The rheological equation of the optimal formula for plugging slurry was established. The plugging performance of the plugging slurry was measured by simulation test. The plugging efficiency of plugging slurry was inspected by four CBM drilling engineering practices.
-
Keywords:
- borehole leakage /
- plugging slurry /
- orthogonal experiment /
- range analysis /
- variance analysis
-
-
[1] 黄维安,邱正松,杨力,等. 煤层气钻井井壁失稳机理及防塌钻井液技术[J]. 煤田地质与勘探,2013,41(2):37-41. HUANG Wei'an,QIU Zhengsong,YANG Li,et al. Instability mechanism of sidewall and anti-sloughing drilling fluid technique for coalbed methane well drilling[J]. Coal Geology & Exploration,2013,41(2):37-41.
[2] 刘延强,徐同台,杨振杰,等. 国内外防漏堵漏技术新进展[J]. 钻井液与完井液,2010,27(6):80-84. LIU Yanqiang,XU Tongtai,YANG Zhenjie,et al. Recent progress on preventing and treating lost circulation domestic and overseas[J]. Drilling Fluid & Completion Fluid,2010,27(6):80-84.
[3] 张希文,李爽,张洁,等. 钻井液堵漏材料及防漏堵漏技术研究进展[J]. 钻井液与完井液,2009,26(6):74-76. ZHANG Xiwen,LI Shuang,ZHANG Jie,et al. Research progress on lost circulation materials and lost circulation control technology[J]. Drilling Fluid & Completion Fluid,2009,26(6):74-76.
[4] 蒋硕忠. 我国化学灌浆技术发展与展望[J]. 长江科学院院报, 2003,20(5):25-27. JIANG Shuozhong. Development and prospect of chemical grouting technique in our country[J]. Journal of Yangtze River Scientific Research Institute,2003,20(5):25-27.
[5] 庞叶青,熊伟,司书芳,等. 新型化学浆液加固工艺的应用[J]. 煤矿安全,2012,43(7):82-84. PANG Yeqing,XIONG Wei,SI Shufang,et al. Study and application of a new chemical grout reinforcement technology[J]. Safety in Coal Mines,2012,43(7):82-84.
[6] 牛磊星,孙平贺. 丙烯酸高吸水膨胀树脂在深部钻探中的堵漏试验[J]. 地质科技情报,2017,36(1):208-211. NIU Leixing,SUN Pinghe. Experimental study on the plugging of acrylic acid high water absorbing resin in deep drilling[J]. Geological Science and Technology Informatica,2017,36(1):208-211.
[7] 张新民,聂勋勇,王平全,等. 特种凝胶在钻井堵漏中的应用[J]. 钻井液与完井液,2007,24(5):83-84. ZHANG Xinmin,NIE Xunyong,WANG Pingquan,et al. A special gel for mud loss control[J]. Drilling Fluid & Completi-on Fluid,2007,24(5):83-84.
[8] 满在山,徐金海,王档良,等. 井壁防渗堵漏注浆模拟试验[J]. 煤炭科学技术,2010,38(10):35-37. MAN Zaishan,XU Jinhai,WANG Dangliang,et al. Grouting simulation experiment on leakage prevention and leakage sealing of mine shaft liner[J]. Coal Science and Technology,2010, 38(10):35-37.
[9] 唐文颖,曹丽文,王晚中,等. 某井田煤田钻孔漏失原因分析[J]. 能源技术与管理,2011(3):8-9. TANG Wenying,CAO Liuwen,WANG Wanzhong,et al. Reason of borehole leakage in a mine[J]. Energy Technology and Management,2011(3):8-9.
[10] 刘瑞江,张业旺,闻崇炜,等. 正交试验设计和分析方法研究[J]. 实验技术与管理,2010,27(9):52-55. LIU Ruijiang,ZHANG Yewang,WEN Chongwei,et al. Study on the design and analysis methods of orthogonal experiment[J]. Experimental Technology and Management,2010, 27(9):52-55.
[11] 董金玉,杨继红,杨国香,等. 基于正交设计的模型试验相似材料的配比试验研究[J]. 煤炭学报,2012,37(1):44-49. DONG Jinyu,YANG Jihong,YANG Guoxiang,et al. Research on similar material proportioning test of model test based on orthogonal design[J]. Journal of China Coal Society,2012, 37(1):44-49.
[12] 王玉枝,袁安峰. 试验设计中对交互作用的处理[J]. 北京联合大学学报(自然科学版),2010,24(4):86-88. WANG Yuzhi,YUAN Anfeng. The treatment of interaction in experimental design[J]. Journal of Beijing Union University(Natural Sciences),2010,24(4):86-88.
[13] 沈崇棠,刘鹤年. 非牛顿流体力学及其应用[M]. 北京:高等教育出版社,1989:147-177. -
