基于角点网格的煤层三维建模与可视化研究

周为喜, 陈玉华, 杨永国, 罗金辉

周为喜, 陈玉华, 杨永国, 罗金辉. 基于角点网格的煤层三维建模与可视化研究[J]. 煤田地质与勘探, 2016, 44(5): 53-57. DOI: 10.3969/j.issn.1001-1986.2016.05.010
引用本文: 周为喜, 陈玉华, 杨永国, 罗金辉. 基于角点网格的煤层三维建模与可视化研究[J]. 煤田地质与勘探, 2016, 44(5): 53-57. DOI: 10.3969/j.issn.1001-1986.2016.05.010
ZHOU Weixi, CHEN Yuhua, YANG Yongguo, LUO Jinhui. 3D modeling and visualization of coal reservoir based on corner-point grid[J]. COAL GEOLOGY & EXPLORATION, 2016, 44(5): 53-57. DOI: 10.3969/j.issn.1001-1986.2016.05.010
Citation: ZHOU Weixi, CHEN Yuhua, YANG Yongguo, LUO Jinhui. 3D modeling and visualization of coal reservoir based on corner-point grid[J]. COAL GEOLOGY & EXPLORATION, 2016, 44(5): 53-57. DOI: 10.3969/j.issn.1001-1986.2016.05.010



基于角点网格的煤层三维建模与可视化研究

基金项目:

国家科技重大专项课题(2011ZX05034-005);国家自然科学基金项目(41202236)

详细信息
    作者简介:

    周为喜(1988-),男,安徽安庆人,硕士研究生,从事地学信息与三维可视化方面工作.E-mail:zhouweixi0925@163.com

    通讯作者:

    陈玉华(1978-),男,安徽淮北人,博士,副教授,从事数学地质与三维建模方面研究.E-mail:chenyuhua@cumt.edu.cn

  • 中图分类号: P631

3D modeling and visualization of coal reservoir based on corner-point grid

Funds:

National Science and Technology Major Project(2011ZX05034-005)

  • 摘要: 在煤层气排采分析及数值模拟研究中,煤储层结构的三维建模是数值模拟和结果分析的起点,具有关键作用。三维长方体等传统网格,难以表达地层的起伏变化,角点网格具有表达起伏变化地层的优势。从煤层气动态可视化的角度出发,基于角点网格建立了煤储层三维地质模型。研究了角点网格模型的数据特点及生成角点网格的方法,采用C#编程语言并结合OpenGL图形接口,开发了煤储层三维可视化软件模型,利用该模型表达了山西省沁水盆地潘庄区块的煤储层地质构造。结果表明,角点网格适用于煤储层三维模型的构建,能较好的表达煤层的结构特征。
    Abstract: In the study of CBM's drainage analysis and numerical simulation, 3D geological model of coal reservoirs structure is the starting point for numerical simulation and results analysis, which plays an important role. Three dimensional cuboids and other traditional grid can not express the changes of strata, but corner-point grid has the advantage of doing it. From the point of dynamic visualization of CBM, the paper established a 3D geological model of coal reservoir based on corner-point grid, studied the characteristics of data and the method to generate corner-point grids of CBM, developed a three dimensional visualization interface of coal reservoir using C# programming language combined with OpenGL graphic interface, expressed the coal reservoir geological structure in Panzhuang area, Qinshui basin, Shanxi Province with the model. The results show that corner-point grid is suitable for constructing 3D model of coal reservoir, which has a good expression of the structural characteristics of coal seam.
计量
  • 文章访问数:  133
  • HTML全文浏览量:  26
  • PDF下载量:  14
  • 被引次数: 0
出版历程
  • 收稿日期:  2014-12-21
  • 网络出版日期:  2021-10-22
