铈改性磁性核壳HZSM-5催化富油煤热解研究

周安宁, 张致, 陈永安, 张怀青, 白状伟, 石智伟, 贺新福

周安宁,张致,陈永安,等. 铈改性磁性核壳HZSM-5催化富油煤热解研究[J]. 煤田地质与勘探,2024,52(7):144−155. DOI: 10.12363/issn.1001-1986.24.01.0003
引用本文: 周安宁,张致,陈永安,等. 铈改性磁性核壳HZSM-5催化富油煤热解研究[J]. 煤田地质与勘探,2024,52(7):144−155. DOI: 10.12363/issn.1001-1986.24.01.0003
ZHOU Anning,ZHANG Zhi,CHEN Yongan,et al. Exploring the pyrolysis of tar-rich coals under the catalysis of cerium-modified magnetic core-shell HZSM-5[J]. Coal Geology & Exploration,2024,52(7):144−155. DOI: 10.12363/issn.1001-1986.24.01.0003
Citation: ZHOU Anning,ZHANG Zhi,CHEN Yongan,et al. Exploring the pyrolysis of tar-rich coals under the catalysis of cerium-modified magnetic core-shell HZSM-5[J]. Coal Geology & Exploration,2024,52(7):144−155. DOI: 10.12363/issn.1001-1986.24.01.0003



铈改性磁性核壳HZSM-5催化富油煤热解研究

基金项目: 陕西省“两链”融合重点专项项目(2023-LL-QY-05);陕西省煤炭联合基金项目(2019JPL-10)
详细信息
    作者简介:

    周安宁,1962年生,男,陕西西安人,博士,教授,博士生导师,从事煤化工新技术及功能材料制备. E-mail:psu564@139.com

  • 中图分类号: TQ530.2

Exploring the pyrolysis of tar-rich coals under the catalysis of cerium-modified magnetic core-shell HZSM-5

  • 摘要:

    【目的】富油煤是集煤、油气属性为一体的宝贵煤炭资源,催化热解是实现其绿色低碳开发的重要途径。然而,高效可回收催化剂的研发仍面临着极大的挑战。【方法】以HZSM-5@SiO2@MgFe2O4 (HSMF)为原料,采用水热法与碱改性制备具有多级孔结构的HZSM-5@SiO2@MgFe2O4 (mHSMF),再通过沉淀法制备铈改性mHSMF (5-CeO2/mHSMF);并利用固定床反应器考察了5-CeO2/mHSMF对神府富油煤热解产物的调控作用及其抗积炭性能。【结果和结论】结果表明,CeO2改性有助于在HSMF表面形成微−介孔多级孔道结构;在5-CeO2/mHSMF催化剂上,650 ℃、N2气氛、反应1 h的条件下,神府富油煤焦油产率达到13.38%,是格金试验焦油产率的176%;相较于原煤热解,催化热解得到的焦油中脂肪烃类及苯类化合物含量分别增加了3.04%和3.07%,煤气中H2和CH4含量提高了10.49%;经CeO2改性后,催化剂的抗积炭性能增幅达86.1%,积炭量仅为11.60 mg/g,且积炭趋于稳定的石墨化结构。5-CeO2/mHSMF对神府富油煤催化热解产物的分布及组成具有明显调控作用,并表现出良好的抗积炭效果和磁性可回收性能。

    Abstract:
    Objective

    Tar-rich coals are valuable resources integrating coal, tar, and gas properties. Catalytic pyrolysis serves as a significant approach for achieving green and low-carbon development of tar-rich coals. However, the research and development of efficient and recyclable catalysts for the pyrolysis of tar-rich coals remains highly challenging.

    Methods

    With HZSM-5@SiO2@MgFe2O4 (HSMF) as the raw material, this study prepared HZSM-5@SiO2@MgFe2O4 (mHSMF) with a hierarchical porous structure using the hydrothermal method and alkali modification, followed by the preparation of cerium-modified mHSMF (5-CeO2/mHSMF) using the precipitation method. Employing a fixed-bed reactor, this study investigated the regulatory effects of 5-CeO2/mHSMF on the pyrolysis products of tar-rich coals from the Shenfu block, along with the anti-carbon deposition performance of 5-CeO2/mHSMF.

    Results and Conclusions

    The results indicate that the CeO2-based modification of HSMF was conducive to the formation of a hierarchical porous structure comprising micropores and mesopores on the surface of HSMF. Through pyrolysis at 650°C in the N2 atmosphere for 1 hr using 5-CeO2/mHSMF as a catalyst, the coals exhibited a tar yield of 13.38%, equivalent to a tar yield of 176% in the Gray-King assay. Compared to the pyrolysis of raw coals, the catalytic pyrolysis exhibited increases in the aliphatic-hydrocarbon and benzene-compound contents in tar of 3.04% and 3.07%, respectively and an increase in the H2 and CH4 content in coal gas of 10.49%. Through CeO2-based modification, the catalyst enhanced the anti-carbon deposition performance by 86.1%, with carbon deposits of merely 11.60 mg/g and tending to form a stable graphitized structure. Overall, 5-CeO2/mHSMF manifests significant regulation of the distribution and composition of the products from the catalytic pyrolysis of coals in the Shenfu block, along with encouraging anti-carbon deposition performance and magnetic recyclability.

  • 图  1   实验装置流程

    注:PV为实际显示值,SV为设置值,p为压力值,F表示出口阀。

    Fig.  1   Experimental setup and process

    图  2   CeO2浸渍改性MgFe2O4系列催化剂XRD图谱

    Fig.  2   XRD patterns of CeO2-modified MgFe2O4 catalysts prepared using the impregnation method

    图  3   催化剂SEM电镜图

    (a) HZSM-5;(b) HZSM-5(mH);(c) 5-CeO2/mH;(d) 5-CeO2/mH/SMF;(e)、(f) 5-CeO2/mHSMF

    Fig.  3   Scanning electron microscope images of catalysts

    图  4   催化剂的N2吸附−脱附等温线

    Fig.  4   N2 adsorption-desorption isotherms of catalysts

    图  5   催化剂的孔径分布

    Fig.  5   Pore size distributions of catalysts

    图  6   5-CeO2/mHSMF催化剂Ce/Fe元素分峰谱图

    Fig.  6   Ce/Fe peak fitting spectra of 5-CeO2/mHSMF

    图  7   催化剂CO2-TPD曲线及 mH、5-CeO2mH的CO2-TPD拟合曲线

    Fig.  7   Temperature-programmed CO2 desorption (CO2-TPD) curves of the various catalysts and fitted CO2-TPD curves of mH and 5-CeO2/mH

    图  8   不同催化剂下焦油组分

    1. None;2. 5-CeO2/mH;3. MgFeCeOx;4. 5-CeO2/SMF;5. 5-CeO2/mHSMF;6. 5-CeO2/mH/SMF

    Fig.  8   Proportions of tar components from pyrolysis under different catalysts

    图  9   催化剂反应后TG曲线

    Fig.  9   Thermogravimetric (TG) curves of catalysts after reactions

    图  10   改性催化剂反应前后的FT-IR谱图

    Fig.  10   FT-IR spectra of modified catalysts before and after reactions

    图  11   改性催化剂反应后Raman谱图

    Fig.  11   Raman spectra of modified catalysts before and after reactions

    表  1   神府煤的工业分析与元素分析

    Table  1   Proximate and ultimate analyses of tar-rich coals from the Shenfu block

    工业分析w/% 元素分析w/%
    Mad Ad Vd FCd* Cd Hd Nd Od* St
    4.17 6.62 36.06 57.32 66.73 4.81 1.34 20.06 0.44
      注:*表示差减法计算结果;St为全硫。
    下载: 导出CSV

    表  2   水热法铈改性系列催化剂比表面积与孔结构参数

    Table  2   Specific surface areas and pore structure parameters of cerium-modified catalysts prepared using the hydrothermal method

    催化剂 SBET/(m2·g−1) Smicro/(m2·g−1) Sext/(m2·g−1) DBJH/nm Vtotal/(10−2 cm3·g−1)
    mH 297.80 229.30 68.51 4.87 12.02
    5-CeO2/mHSMF 245.91 148.64 97.27 7.87 7.46
    5-CeO2/mH/SMF 134.27 135.77 9.10 22.02
    MgFeCeOx 8.99 3.14 5.85 23.71 0.16
    5-CeO2/mH 259.52 203.60 55.92 10.71 4.94
      注:SBET为催化剂的比表面积;Smicro为催化剂微孔的比表面积;Sext为催化剂的外比表面积;DBJH为催化剂的孔径;Vtotal为催化剂的孔体积。
    下载: 导出CSV

    表  3   5-CeO2/mHSMF中主要金属元素相对含量

    Table  3   Relative contents of major metal elements in 5-CeO2/mHSMF

    元素 结合能/eV 半峰宽/eV 原子百分比/% 相对误差/% 质量分数/%
    O 1s 531.20 4.07 53.90 1.69 37.80
    Fe 2p3/2 712.20 3.32 3.00 0.41 7.20
    Mg 1s 1307.20 4.08 7.40 0.79 7.80
    Ce 3d5/2 884.20 8.18 5.10 0.42 31.00
    下载: 导出CSV

    表  4   浸渍法CeO2改性催化剂的热解产物质量分数

    Table  4   Mass fractions of products from pyrolysis under CeO2-modified catalysts prepared using the impregnation method %

    催化剂 焦油产率 热解水产率 气体产率 半焦产率
    8.37 6.95 13.76 70.92
    5-CeO2/MgFe2O4 11.61 6.08 13.40 68.91
    5-CeO2/SMF 10.58 6.41 13.92 69.09
    5-CeO2/HSMF 13.08 6.42 12.81 67.69
    下载: 导出CSV

    表  5   水热法CeO2改性催化剂的热解产物质量分数

    Table  5   Mass fractions of products from pyrolysis under CeO2-modified catalysts prepared using the hydrothermal method %

    催化剂 焦油产率 热解水产率 气体产率 半焦产率
    8.37 6.95 13.76 70.92
    5-CeO2/mH 8.61 6.59 16.13 68.67
    MgFeCeOx 10.85 5.22 14.34 69.59
    5-CeO2/mHSMF 13.38 5.17 14.09 67.36
    5-CeO2/mH/SMF 11.47 6.01 14.26 68.26
    下载: 导出CSV

    表  6   不同催化剂下热解煤气组成占比

    Table  6   Pyrolysis gas composition under different catalysts %

    催化剂 H2 CH4 CO2 CO C2H4 C2H6 C3H6 C3H8
    24.52 32.07 18.92 16.53 1.83 2.97 1.91 1.25
    5-CeO2/mH 25.72 38.51 14.32 10.89 1.56 3.52 3.01 2.47
    MgFeCeOx 21.42 41.67 13.52 12.26 2.38 4.61 2.26 1.88
    5-CeO2/mHSMF 31.22 36.86 11.93 11.68 1.05 4.62 1.29 1.35
    5-CeO2/mH/SMF 22.96 39.42 16.31 10.39 0.83 4.93 3.52 1.64
    下载: 导出CSV

    表  7   热解煤焦油GC/MS组成占比

    Table  7   Proportions of the GC/MS components of coal tar from pyrolysis %

    催化剂 苯类 酚类 脂肪烃 稠环芳烃 其他
    1.86 17.73 15.69 34.82 29.90
    HZSM-5 2.57 17.23 16.43 31.04 32.73
    5-CeO2/mH 2.88 18.13 17.95 30.23 30.81
    MgFeCeOx 4.73 17.33 18.25 31.02 28.67
    5-CeO2/mHSMF 4.93 16.96 18.73 29.51 29.87
    5-CeO2/mH/SMF 4.06 18.25 17.12 30.91 29.66
    下载: 导出CSV
  • [1] 王双明,王虹,任世华,等. 西部地区富油煤开发利用潜力分析和技术体系构想[J]. 中国工程科学,2022,24(3):49−57. DOI: 10.15302/J-SSCAE-2022.03.006

    WANG Shuangming,WANG Hong,REN Shihua,et al. Potential analysis and technical conception of exploitation and utilization of tar-rich coal in western China[J]. Strategic Study of CAE,2022,24(3):49−57. DOI: 10.15302/J-SSCAE-2022.03.006

    [2] 王双明,师庆民,王生全,等. 富油煤的油气资源属性与绿色低碳开发[J]. 煤炭学报,2021,46(5):1365−1377.

    WANG Shuangming,SHI Qingmin,WANG Shengquan,et al. Resource property and exploitation concepts with green and low-carbon of tar-rich coal as coal-based oil and gas[J]. Journal of China Coal Society,2021,46(5):1365−1377.

    [3]

    SHI Qingmin,MI Yichen,WANG Shuangming,et al. Pyrolysis behavior of tar-rich coal with various coal-forming environments:A TGA and in situ transmission FTIR study[J]. Fuel,2024,358:130250. DOI: 10.1016/j.fuel.2023.130250

    [4]

    ZHAO Yan,SHI Qiong,LI Zonglu,et al. Preparation of carbon-based microwave absorbing materials by hybrid activation pyrolysis of lignin and coal[J]. Materials Letters,2022,328:133155. DOI: 10.1016/j.matlet.2022.133155

    [5]

    LANCET D,PECHT I. Spectroscopic and immunoch-emical studies with nitrobenzoxadiazolealanine,a fluorescent dinitrophenyl analog[J]. Biochemistry,1977,16(23):5150−5157. DOI: 10.1021/bi00642a031

    [6] 刘瑞春,牛犇,张君涛,等. 煤热解工艺及其增油技术研究进展[J]. 现代化工,2022,42(7):37−41.

    LIU Ruichun,NIU Ben,ZHANG Juntao,et al. Advances in coal pyrolysis process and oil-enhancing technology[J]. Modern Chemical Industry,2022,42(7):37−41.

    [7] 卫小芳,王建国,丁云杰. 煤炭清洁高效转化技术进展及发展趋势[J]. 中国科学院院刊,2019,34(4):409−416.

    WEI Xiaofang,WANG Jianguo,DING Yunjie. Progress and development trend of clean and efficient coal utilization technology[J]. Bulletin of Chinese Academy of Sciences,2019,34(4):409−416.

    [8] 穆飞,倪效磊,乔英云,等. 煤催化热解焦油提质研究进展[J]. 现代化工,2022,42(7):51−55.

    MU Fei,NI Xiaolei,QIAO Yingyun,et al. Research progress on upgrading tar in coal catalytic pyrolysis[J]. Modern Chemical Industry,2022,42(7):51−55.

    [9] 李刚,张穗穗,张妮娜,等. MeMo/USY催化剂对神东煤热解产物的调控[J]. 化工进展,2019,38(3):1329−1337.

    LI Gang,ZHANG Suisui,ZHANG Nina,et al. Regulation of Shendong coal pyrolysis products based on MeMo/USY catalyst[J]. Chemical Industry and Engineering Progress,2019,38(3):1329−1337.

    [10]

    SHI Pengcheng,CHANG Guozhang,TAN Xiaoli,et al. Enhancement of bituminous coal pyrolysis for BTX production by Fe2O3/MoSi2-HZSM-5 catalysts[J]. Journal of Analytical and Applied Pyrolysis,2020,150:104867. DOI: 10.1016/j.jaap.2020.104867

    [11] 张穗穗,李刚,闵小建,等. MxOy/USY双功能催化剂对神东煤的快速热解产物的调控[J]. 化工进展,2018,37(8):3029−3037.

    ZHANG Suisui,LI Gang,MIN Xiaojian,et al. Regulation of the rapid pyrolysis products of Shendong coal by MxOy/USY bifunctional catalyst[J]. Chemical Industry and Engineering Progress,2018,37(8):3029−3037.

    [12] 薛爽,骆仲泱,孙浩然,等. 金属改性结合核壳结构协同调控酶解木质素催化热解液体产物分布的研究[J]. 燃烧科学与技术,2022,28(5):507−513.

    XUE Shuang,LUO Zhongyang,SUN Haoran,et al. Regulation of metal modification combined with core-shell structure on liquid products during catalytic fast pyrolysis of enzymatic hydrolysis lignin[J]. Journal of Combustion Science and Technology,2022,28(5):507−513.

    [13] 王德亮,陈兆辉,余剑,等. 不同硅铝比HZSM-5分子筛对煤热解挥发物催化提质的影响[J]. 燃料化学学报,2021,49(5):634−640. DOI: 10.1016/S1872-5813(21)60030-0

    WANG Deliang,CHEN Zhaohui,YU Jian,et al. Effect of Si/Al ratio of HZSM-5 zeolites on catalytic upgrading of coal pyrolysis volatiles[J]. Journal of Fuel Chemistry and Technology,2021,49(5):634−640. DOI: 10.1016/S1872-5813(21)60030-0

    [14] 杨珍,曹景沛,朱陈,等. B-ZSM-5酸调控及催化褐煤热解挥发分制轻质芳烃研究[J]. 化工学报,2021,72(11):5633−5642.

    YANG Zhen,CAO Jingpei,ZHU Chen,et al. Catalytic conversion of lignite pyrolysis volatiles for enriching light aromatics over B-ZSM-5[J]. CIESC Journal,2021,72(11):5633−5642.

    [15]

    GAO Shasha,TANG Yakun,WANG Lei,et al. NiFe nanoalloys in-situ immobilized on coal based activated carbons through one-step pyrolysis as magnetically recoverable catalysts for reduction of 4-nitrophenol[J]. Journal of Alloys and Compounds,2017,702:531−537. DOI: 10.1016/j.jallcom.2016.12.375

    [16] 张蕾,陈雅,贾阳,等. 煤制兰炭过程中挥发性有机污染物和臭氧协同处理机理[J]. 西安科技大学学报,2024,44(1):135−143.

    ZHANG Lei,CHEN Ya,JIA Yang,et al. Synergistic treatment mechanism of volatile organic pollutants and ozone in coal-based semi-coke process[J]. Journal of Xi’an University of Science and Technology,2024,44(1):135−143.

    [17]

    SMIRNOV A N,KRYLOVA S A,PETUKHOV V N,et al. Conversion of coal over an oxide catalyst produced from natural high-magnesia siderite[J]. Coke and Chemistry,2019,62(10):468−473. DOI: 10.3103/S1068364X19100119

    [18] 张军兴,周安宁,闫宁,等. 磁性Mo/HZSM-5@SiO2@Fe3O4催化剂可控制备及煤催化热解[J]. 煤炭学报,2021,46(6):1985−1994.

    ZHANG Junxing,ZHOU Anning,YAN Ning,et al. Controlled preparation and catalytic pyrolysis of coal over magnetic Mo/HZSM-5@SiO2@Fe3O4 catalyst[J]. Journal of China Coal Society,2021,46(6):1985−1994.

    [19] 陈永安,周安宁,李云龙,等. 磁性MgFe2O4及其核壳催化剂制备与煤热解性能研究[J]. 化工学报,2022,73(7):3026−3037.

    CHEN Yongan,ZHOU Anning,LI Yunlong,et al. Preparation and coal pyrolysis performance of magnetic MgFe2O4 and its core-shell catalysts[J]. CIESC Journal,2022,73(7):3026−3037.

    [20]

    HOFF T C,HOLMES M,PROANO-AVILES J,et al. Decoupling the role of external mass transfer and intracrystalline pore diffusion on the selectivity of HZSM-5 for the catalytic fast pyrolysis of biomass[J]. ACS Sustainable Chemistry & Engineering,2017,5(10):8766−8776.

    [21]

    GAO Junhua,ZHOU Hao,ZHANG Fucan,et al. Effect of preparation method on the catalytic performance of HZSM-5 zeolite catalysts in the MTH reaction[J]. Materials,2022,15(6):2206. DOI: 10.3390/ma15062206

    [22]

    WU Hong,LIU Fei,YI Yun,et al. Catalytic and deactivated behavior of SAPO-34/ZSM-5 composite molecular sieve synthesized by in situ two-step method[J]. Journal of Materials Research and Technology,2021,15:1844−1853. DOI: 10.1016/j.jmrt.2021.09.017

    [23] 张云鹏,李明罡,邢恩会,等. 不同结构扩孔分子筛催化MTP反应行为及表面积炭物种表征[J]. 燃料化学学报,2018,46(9):1101−1112.

    ZHANG Yunpeng,LI Minggang,XING Enhui,et al. Methanol to propylene reaction performance and trapped carbonaceous species over zeolites with different topologies[J]. Journal of Fuel Chemistry and Technology,2018,46(9):1101−1112.

    [24]

    DAI Gongxin,WANG Shurong,ZOU Qun,et al. Improvement of aromatics production from catalytic pyrolysis of cellulose over metal-modified hierarchical HZSM-5[J]. Fuel Processing Technology,2018,179:319−323. DOI: 10.1016/j.fuproc.2018.07.023

    [25]

    JIN Tao,WANG Hongtao,PENG Jiebang,et al. Catalytic pyrolysis of lignin with metal-modified HZSM-5 as catalysts for monocyclic aromatic hydrocarbons production[J]. Fuel Processing Technology,2022,230:107201. DOI: 10.1016/j.fuproc.2022.107201

    [26]

    KHEZRI H,IZADBAKHSH A,IZADPANAH A A. Promotion of the performance of La,Ce and Ca impregnated HZSM-5 nanoparticles in the MTO reaction[J]. Fuel Processing Technology,2020,199:106253. DOI: 10.1016/j.fuproc.2019.106253

    [27]

    LÖFBERG A,GUERRERO-CABALLERO J,KANE T,et al. Ni/CeO2 based catalysts as oxygen vectors for the chemical looping dry reforming of methane for syngas production[J]. Applied Catalysis B:Environmental,2017,212:159−174. DOI: 10.1016/j.apcatb.2017.04.048

    [28] 李睿杰,章菊萍,史健,等. Ni/CeO2催化剂的金属−载体界面调控及其低温化学链甲烷干重整性能研究[J]. 燃料化学学报,2022,50(11):1458−1470. DOI: 10.1016/S1872-5813(22)60032-X

    LI Ruijie,ZHANG Juping,SHI Jian,et al. Regulation of metal-support interface of Ni/CeO2 catalyst and the performance of low temperature chemical looping dry reforming of methane[J]. Journal of Fuel Chemistry and Technology,2022,50(11):1458−1470. DOI: 10.1016/S1872-5813(22)60032-X

    [29]

    LI Xin,REZAEI F,LUDLOW D K,et al. Synthesis of SAPO-34@ZSM-5 and SAPO-34@Silicalite-1 Core-Shell Zeolite Composites for Ethanol Dehydration[J]. Industrial & Engineering Chemistry Research,2018,57(5):1446−1453.

    [30]

    BÊCHE E,CHARVIN P,PERARNAU D,et al. Ce 3d XPS investigation of cerium oxides and mixed cerium oxide (CexTiyOz)[J]. Surface & Interface Analysis,2008,40(3/4):264−267.

    [31] 孟竹辉,刘倩,钟文琪,等. Ni-Ce-La/HZSM-5催化焦油模化物甲苯重整反应研究[J]. 太阳能学报,2023,44(3):260−269.

    MENG Zhuhui,LIU Qian,ZHONG Wenqi,et al. Study on Ni-Ce-La/HZSM-5 catalyzed reformation of tar modle compounds toluene[J]. Acta Energiae Solaris Sinica,2023,44(3):260−269.

    [32]

    TANG Songshan,ZHANG Changsen,XUE Xiangfei,et al. Catalytic pyrolysis of lignin over hierarchical HZSM-5 zeolites prepared by post-treatment with alkaline solutions[J]. Journal of Analytical and Applied Pyrolysis,2019,137:86−95. DOI: 10.1016/j.jaap.2018.11.013

    [33]

    OU Zhiliang,RAN Jingyu,QIU Huayu,et al. Uncovering the effect of surface basicity on the carbon deposition of Ni/CeO2 catalyst modified by oxides in DRM[J]. Fuel,2023,335:126994. DOI: 10.1016/j.fuel.2022.126994

    [34] 李勇,闫伦靖,李晓荣,等. 酸/碱催化剂对低阶煤热解挥发分转化行为的作用机制研究[J]. 化工学报,2022,73(3):1173−1183.

    LI Yong,YAN Lunjing,LI Xiaorong,et al. Study on the mechanism of acid/base catalyst on the release behavior of volatiles during low rank coal pyrolysis[J]. CIESC Journal,2022,73(3):1173−1183.
