大宁−吉县区块深层煤层气井酸化压裂产气效果影响因素分析

李曙光; 王红娜; 徐博瑞; 甄怀宾; 王成旺; 袁朴

doi:10.12363/issn.1001-1986.21.12.0800

大宁−吉县区块深层煤层气井酸化压裂产气效果影响因素分析

李曙光^{1, 2,},
王红娜³,
徐博瑞^{1, 2},
甄怀宾^{1, 2},
王成旺^{1, 2},
袁朴^{1, 2}

1.
中联煤层气国家工程研究中心有限责任公司，北京 100095
2.
中石油煤层气有限责任公司，北京 100028
3.
中油油气勘探软件国家工程研究中心有限公司，北京 100080

基金项目: 国家科技重大专项项目(2016ZX05042)

详细信息

作者简介:
李曙光，1967年生，男，浙江余姚人，博士，教授级高级工程师，从事煤层气、致密气、页岩气地质工程一体化评价、储层改造工艺研究、压裂液体系配方研发等研究工作. E-mail：57990696@qq.com

中图分类号: TE-9
计量
- 文章访问数: 486
- HTML全文浏览量: 48
- PDF下载量: 137
出版历程
- 收稿日期: 2021-12-13
- 修回日期: 2022-01-19
- 网络出版日期: 2022-03-18
- 发布日期: 2022-03-24

Influencing factors on gas production effect of acid fractured CBM Wells in deep coal seam of Daning-Jixian Block

LI Shuguang^{1, 2,},
WANG Hongna³,
XU Borui^{1, 2},
ZHEN Huaibin^{1, 2},
WANG Chengwang^{1, 2},
YUAN Pu^{1, 2}

1.
China United Coalbed Methane National Engineering Research Center Co., Ltd., Beijing100095, China
2.
PetroChina Coalbed Methane Company Limited, Beijing 100028, China
3.
CNPC Exploration Software Co., Ltd, Beijing 100080, China

摘要

摘要: 大宁−吉县区块深层8号煤层面积大、厚度大、分布广、煤层气资源富集，体积酸压后试采获得突破，但试采井产能差异大，产能主控因素不明确，严重制约煤层气开发进程。针对大宁−吉县区块2 000 m以深的上石炭统本溪组8号煤层试采井，从地质条件、酸压施工和排采制度中选取28个典型评价指标，运用灰色关联方法对煤层气井酸压后产能进行敏感性分析并提出相应技术对策。结果表明：酸压施工因素对产能的影响高于地质因素和排采因素；砂量、酸量、见气前产水指数、泥质含量和阵列感应电阻率是影响该区块气井产能的主控因素，可将阵列感应电阻率和泥质含量作为筛选有利区的重要指标；提出采用低密度、低粒径支撑剂提高支撑剂运移距离与支撑裂缝长度；控制排采速度不超过200 m³/d，以保证深层煤层气平稳连续产出。该研究可为深层煤层气有利区筛选、施工参数优化以及排采制度调整提供参考。
- 深层煤层气 /
- 体积酸压 /
- 煤层气产能 /
- 影响因素 /
- 灰色关联 /
- 大宁−吉县区块
Abstract: The No.8 deep coal seam in Daning-Jixian Block is large, thick, widely distributed, and rich in coalbed methane(CBM) resources. After volume acid fracturing, a breakthrough has been achieved in the producing test. However, the productivity of the testing wells varies greatly, and the major controlling factors of productivity are not clear, severely restricting the CBM development. In this paper, the testing wells in the No.8 coal seam with a buried depth of more than 2 000 m of the Upper Carboniferous Benxi Formation in Daning-Jixian Block were taken as the research object, and 28 typical evaluation indicators were selected from geological conditions, acid fracturing construction and drainage technology. The grey correlation method was applied to analyze the production sensitivity of CBM wells after acid fracturing, and corresponding technical measures were presented. The results show that factors of acid fracturing construction have a greater impact on productivity than geological factors and drainage factors. Sand volume, acid dosage, water production index before CBM breakthrough, mud content and array induction resistivity(M2RX) are the main controlling factors of productivity. The M2RX and mud content can be used as important indicators to screen out favorable areas. Low density and small particle size proppants are proposed to increase the migration distance of proppants and the propped fracture length. Gas production rate is controlled below 200 m³/d to ensure the smooth and continuous production of deep CBM. This research could provide reference for the selection of favorable areas, optimization of construction parameters and adjustment of drainage and production systems.
- deep coalbed methane /
- volume acid fracturing /
- coalbed methane productivity /
- influencing factor /
- grey correlation /
- Daning-Jixian Block

HTML全文

图 1 深层8号煤裂隙发育照片

Fig. 1 Development of cleats and fissures in the deep No.8 coal seam

下载: 全尺寸图片幻灯片

图 2 典型井排采曲线

Fig. 2 Typical well drainage curves

下载: 全尺寸图片幻灯片

图 3 8号煤顶板构造及分析井位置

Fig. 3 Location map of analysis wells

下载: 全尺寸图片幻灯片

表 1 10%盐酸浸泡前后煤岩抗压强度变化

Table 1 Changes of coal compressive strength before and after soaking in 10% hydrochloric acid

岩心编号	抗压强度/MPa		备注
岩心编号	天然状态	酸化后	备注
煤心1	30.27	28.80	均为紧邻钻取岩心对比
煤心2	27.52	22.05
煤心3	24.95	15.78

下载: 导出CSV

表 2 10%盐酸浸泡前后煤岩气测渗透率对比

Table 2 Comparison of measured permeability of coal and gas before and after soaking in 10% hydrochloric acid

岩心编号	渗透率/10⁻³ μm²
岩心编号	原始状态	浸泡后	浸泡后/原始状态比值
煤心4	0.054 7	0.554 5	10.14
煤心5	0.014 1	0.124 9	8.86
煤心6	0.059 8	0.956 1	15.99
煤心7	0.013 3	0.155 6	11.70

下载: 导出CSV

表 3 试验井的地质、工程和生产参数

Table 3 Geological, engineering and production parameters of test wells

井号	地质参数
井号	电阻率/ (Ω·m)	泥质质量分数/%	储层有效厚度/m	射孔厚度/m	自然伽马/API	声波时差/ (μs·m⁻¹)	含气量/ (m³·t⁻¹)	高程/ m	储层压力/MPa	密度/ (g·cm⁻³)	临界解吸压力/MPa	孔隙率/%	临储比	井径扩大率/%	构造曲率
DJ3-2	588	12.3	9.8	5.5	54.5	363	28.2	−710	19.7	1.45	19.7	4.34	1.00	0.01	0.10
DJ3-4	535	12.3	8.9	6.0	48.3	382	27.5	−917	21.3	1.45	21.3	4.40	1.00	6.16	0.07
DJ3-6	648	15.5	7.5	3.5	45.4	397	27.2	−1 089	22.9	1.43	22.8	4.28	1.00	6.02	0.09
DJ3-7	522	14.5	7.6	5.0	46.3	376	27.8	−955	22.2	1.49	22.2	4.58	1.00	1.48	0.10
DJ6-10	279	15.1	7.9	4.5	35.4	401	28.7	−1 124	20.8	1.50	18.8	4.34	0.90	9.65	0.12
DJ7-5	560	17.7	7.3	5.0	49.7	404	29.2	−996	22.2	1.47	20.8	2.80	0.93	12.24	0.08
DJ4-8	77	16.9	7.6	4.0	58.5	390	27.7	−1 018	22.1	1.42	19.5	4.94	0.88	19.90	0.13

下载: 导出CSV

井号	酸压施工参数											排采参数
井号	每米加砂强度/ (m³·m^–1)	总砂量/m³	氢离子量/10⁹ mol	施工排量/ (m³·min^–1)	总液量/m³	监测裂缝破裂面积/m²	清洁液量加液强度/ (m·m^–3)	清洁液量/m³	前置液占压裂液比值	平均砂比/%	停泵压力/MPa	见气前产水指数/ (m³·d⁻¹·MPa⁻¹)	产气时井底流压/ MPa
DJ3-2	4.08	40.0	1.55	11.5	1 905.0	30 225	153.88	1 508	0.21	2.5	40.0	25.44	17.90
DJ3-4	2.14	12.7	0.83	7.5	1 011.5	20 489	87.69	520	0.49	5.4	28.7	7.63	20.40
DJ3-6	1.44	10.8	3.21	7.5	1 346.0	83 790	132.93	997	0.26	1.7	31.5	22.94	20.27
DJ3-7	5.03	38.2	2.87	9.8	1 135.0	18 840	64.74	492	0.57	10.0	35.2	8.46	18.13
DJ6-10	3.92	31.0	4.55	10.5	1 290.0	29 673	108.86	860	0.33	4.1	39.6	9.34	15.34
DJ7-5	7.26	53.0	5.55	12.0	1 879.0	76 381	158.63	1 158	0.38	4.8	16.8	46.55	20.90
DJ4-8	0.20	1.5	2.41	6.0	1 510.0	85 376	151.32	1 150	0.24	2.00	37.6	5.35	15.63

下载: 导出CSV

表 4 煤层气井酸压后产能灰色关联度及排序

Table 4 Grey correlation degree and ranking of CBM well productivity after acid fracturing

参数类别	影响因素	关联度	排序	参数类别	影响因素	关联度	排序
酸压	每米加砂强度	0.961 9	1	地质	自然伽马	0.806 1	15
酸压	总砂量	0.948 7	2	地质	声波时差	0.803 6	16
排采	见气前米产水指数	0.915 0	3	地质	含气量	0.802 8	17
酸压	酸液用量	0.912 7	4	地质	高程	0.798 9	18
酸压	施工排量	0.870 6	5	地质	储层压力	0.798 6	19
酸压	总液量	0.863 7	6	地质	密度	0.791 3	20
地质	电阻率	0.857 8	7	地质	临界解吸压力	0.789 8	21
地质	泥质含量	0.846 0	8	地质	临储比	0.780 7	22
酸压	监测裂缝破裂面积	0.842 3	9	地质	井径扩大率	0.734 7	23
酸压	清洁液量加液强度	0.839 5	10	地质	构造曲率	0.726 8	24
地质	储层有效厚度	0.831 6	11	酸压	平均砂比	0.675 0	25
酸压	清洁液量	0.827 3	12	地质	测井孔隙率	0.657 8	26
酸压	前置液占压裂液比值	0.821 7	13	排采	井底流压降	0.600 2	27
地质	射孔厚度	0.806 2	14	酸压	停泵压力	0.582 5	28

下载: 导出CSV

表 5 煤层气井酸压后产能影响因素排序

Table 5 Sequence of factors affecting productivity of coalbed methane wells after acid fracturing

类别	关联度平均值	排序
酸压	0.831 4	1
地质	0.788 8	2
排采	0.757 6	3

下载: 导出CSV
